Taper Length • DRILLS
175

Taper Length Parabolic Flute High Speed Steel Deep Hole Drills QuanTiTy Per Package
Size
135° Split Point • TiN Coated • Heavy Duty 1/16" thru 9/32" QuanTiTy
12
19/64" thru 1/2" 6
#1 thru #42 12
Prices shown are per drill.
number SizeS [A59-TiN]
FLuTe
Size LengTH overaLL orDer Price
eacH
LengTH
#
#1 3-3/4" 6-1/8" 09-050-401 $34.61
2 3-3/4 6-1/8 09-050-402 34.61
3 3-5/8 6 09-050-403 31.50
4 3-5/8 6 09-050-404 31.50
5 3-5/8 6 09-050-405 31.50
6 3-5/8 6 09-050-406 31.50
7 3-5/8 6 09-050-407 31.50
8 3-5/8 6 09-050-408 31.50
9 3-5/8 6 09-050-409 31.50
10 3-5/8 6 09-050-410 31.50
11 3-5/8 6 09-050-411 31.50 FracTionaL SizeS [A59-TiN]
12 3-5/8 6 09-050-412 31.50 Size FLuTe overaLL orDer Price APPLICATIONS:
13 3-3/8 5-3/4 09-050-413 28.56 LengTH LengTH # eacH • Designed for general purpose, heavy duty drilling
14 3-3/8 5-3/4 09-050-414 28.56 1/16" 1-3/4" 3" 09-050-304 $10.09 operations for tougher materials.
15 3-3/8 5-3/4 09-050-415 28.56 5/64 2 3-3/4 09-050-305 10.09 • The flute design offers open fluting, heavy parallel web
16 3-3/8 5-3/4 09-050-416 28.56 3/32 2-1/4 4-1/4 09-050-306 12.17 and a higher helix angle.
17 3-3/8 5-3/4 09-050-417 28.56 7/64 2-1/2 4-5/8 09-050-307 15.12 • 135° point works very well for drilling alloy steels, cast
18 3-3/8 5-3/4 09-050-418 26.60 1/8 2-3/4 5-1/8 09-050-308 15.17 iron, manganese steels, harder stainless steels and a
19 3-3/8 5-3/4 09-050-419 24.17 9/64 3 5-3/8 09-050-309 21.25 variety of other tougher ferrous and non-ferrous metals
20 3-3/8 5-3/4 09-050-420 26.60 5/32 3 5-3/8 09-050-310 19.32 and alloys.
21 3-3/8 5-3/4 09-050-421 26.60 11/64 3-3/8 5-3/4 09-050-311 25.50 • The split point reduces the required drilling thrust & aids
22 3-3/8 5-3/4 09-050-422 24.17 3/16 3-3/8 5-3/4 09-050-312 24.00 centering the drill.
23 3 5-3/8 09-050-423 23.03 13/64 3-5/8 6 09-050-313 27.44 • Used with manual drills, portable or stationary machines.
24 3 5-3/8 09-050-424 23.03 7/32 3-5/8 6 09-050-314 29.10
25 3 5-3/8 09-050-425 23.03 15/64 3-3/4 6-1/8 09-050-315 30.18 • For best results, use cutting fluids and lubricants.
26 3 5-3/8 09-050-426 23.03 1/4 3-3/4 6-1/8 09-050-316 26.46 FeATureS:
27 3 5-3/8 09-050-427 23.03 17/64 3-7/8 6-1/4 09-050-317 33.20 • Right hand (clockwise rotation) cutting direction.
28 3 5-3/8 09-050-428 23.03 9/32 3-7/8 6-1/4 09-050-318 31.47 • Offers open fluting, heavy parallel web and a higher
29 3 5-3/8 09-050-429 20.94 19/64 4 6-3/8 09-050-319 39.57
30 3 5-3/8 09-050-430 23.03 5/16 4 6-3/8 09-050-320 38.13 helix angle.
31 2-3/4 5-1/8 09-050-431 20.34 21/64 4-1/8 6-1/2 09-050-321 42.06 • Spiral - helical flutes.
32 2-3/4 5-1/8 09-050-432 20.34 11/32 4-1/8 6-1/2 09-050-322 42.69 • Straight shanks correspond to the drill diameter.
33 2-3/4 5-1/8 09-050-433 20.34 23/64 4-1/4 6-3/4 09-050-323 49.59 • Taper length drills have flutes proportional to length.
34 2-3/4 5-1/8 09-050-434 20.34 3/8 4-1/4 6-3/4 09-050-324 54.34 • Increased web for deeper holes or clearing drill bushings.
35 2-3/4 5-1/8 09-050-435 20.34 25/64 4-3/8 7 09-050-325 57.10 TiN Coated
36 2-1/2 4-5/8 09-050-436 20.21 13/32 4-3/8 7 09-050-326 60.52 • For less galling & edge build-up increase speed up to
37 2-1/2 4-5/8 09-050-437 20.21 27/64 4-5/8 7-1/4 09-050-327 63.15 100% or feed up to 50%.
38 2-1/2 4-5/8 09-050-438 20.21 7/16 4-5/8 7-1/4 09-050-328 70.48
39 2-1/2 4-5/8 09-050-439 18.38 29/64 4-3/4 7-1/2 09-050-329 79.26
40 2-1/2 4-5/8 09-050-440 20.21 15/32 4-3/4 7-1/2 09-050-330 76.37
41 2-1/2 4-5/8 09-050-441 20.21 31/64 4-3/4 7-3/4 09-050-331 76.16
42 2-1/4 4-1/4 09-050-442 14.81 1/2 4-3/4 7-3/4 09-050-332 73.41
8% cobalt ag coated Power Long Drills
118° Point Angle

BeNeFITS: APPLICATIONS: FeATureS:
• Unique flute geometry allows for • Non-step drilling up to 20XD in cast • Premium high speed steel cobalt
excellent chip removal. iron, alloy steel & carbon steels. with composite multi-layer AG
• Longer tool life than your regular • Suitable for drilling in carbon steel, TiAlN coating. noTe:
high speed steel & high speed steel alloy steel, cast iron, die steel & †Ships direct from factory.
cobalt drills. stainless steel. • Pre-hole should be drilled.
DecimaL SHank FLuTe overaLL orDer Price DecimaL SHank FLuTe overaLL orDer Price
Size Size
DiameTer DiameTer LengTH LengTH # eacH DiameTer DiameTer LengTH LengTH # eacH
1/8" 0.1250" 1/8" 69mm 106mm 01-021-600 $22.23 1/4" 0.2500" 1/4" 150mm 215mm 01-021-642 $72.73
1/8" 0.1250" 1/8" 105mm 155mm 01-021-602 27.39 1/4" 0.2500" 1/4" 190mm 275mm 01-021-644 86.34
9/64" 0.1406" 9/64" 115mm 165mm 01-021-608 27.39 17/64" 0.2656" 17/64" 155mm 225mm 01-021-648 72.73
9/64" 0.1406" 9/64" 145mm 210mm 01-021-610 43.56 5/16" 0.3123" 5/16" 165mm 240mm 01-021-660 106.86
5/32" 0.1563" 5/32" 78mm 119mm 01-021-612 23.81 5/16" 0.3123" 5/16" 210mm 305mm 01-021-662 121.83
5/32" 0.1563" 5/32" 120mm 175mm 01-021-614 29.52 21/64" 0.3281" 21/64" 109mm 165mm 01-021-664 87.54
5/32" 0.1563" 5/32" 150mm 220mm 01-021-616 46.62 21/64" 0.3281" 21/64" 165mm 240mm 01-021-666 113.96
3/16" 0.1875" 3/16" 135mm 195mm 01-021-626 40.09 11/32" 0.3437" 11/32" 175mm 250mm 01-021-670 128.31
3/16" 0.1875" 3/16" 170mm 245mm 01-021-628 61.28 3/8" 0.3750" 3/8" 185mm 265mm 01-021-678 166.22
1/4" 0.2500" 1/4" 97mm 148mm 01-021-640 53.54
