MaxiMill 211 system
B122
XD..

P ●●●●●●○○○ ○ ○
M ● ○○●●● ●
K ○●●● ●●●● ○●●○ ●
N ●●●●
S ●●
H ○ ●
CTEP210 TCM10 CTCP220 CTPP225 CTCP230 CTPP235 CTPM225 CTCM235 CTPM240 CTN3105 CTL3215 CTCK215 CTPK220 CTD4205 AMZ H216T CTW4615 CTC5235 CTC5240 CTP6215 d l s l 1 r d 1

1.0
4.90
3.18
XDKT 070304SR-M50 ●● ● [mm] [mm] [mm] [mm] [mm] [mm]
7.80
0.40
2.50
XDKT 070308SR-M50 ●● ● 4.90 7.80 3.18 1.0 0.80 2.50
XDKT 11T304SR-M50 ●● ● ● 6.80 10.60 3.80 1.8 0.40 2.80
XDKT 11T308SR-M50 ●●●●●●● ●● 6.80 10.60 3.80 1.4 0.80 2.80
XDKT 11T312SR-M50 ●● ● 6.80 10.60 3.80 1.0 1.20 2.80
XDKT 11T312SR-R50 ● 6.80 10.60 3.80 1.0 1.20 2.80
XDKT 11T320SR-M50 ●● ● 6.80 10.60 3.80 2.1 2.00 2.80
-M50 XDKT 11T325SR-M50 ●● 6.80 10.60 3.80 1.6 2.50 2.80
XDKT 11T332SR-M50 ● 6.80 10.60 3.80 1.5 3.20 2.80
XDKT 150508SR-M50 ●●●●●●● ●● 9.30 14.80 5.56 1.6 0.80 4.50
XDKT 150512SR-M50 ●● ● 9.30 14.80 5.56 1.2 1.20 4.50
XDKT 150516SR-M50 ●● ● 9.30 14.80 5.56 0.8 1.60 4.50
XDKT 150520SR-M50 ● 9.30 14.80 5.56 0.6 2.00 4.50
XDKT 150530SR-M50 ●● ● 9.30 14.80 5.56 3.00 4.50
XDKT 150540SR-M50 ●● ● 9.30 14.80 5.56 4.00 4.50
XDKT 11T304SR-R50 ●● 6.80 10.60 3.80 1.8 0.40 2.80
XDKT 11T308SR-R50 ●●●●● ● 6.80 10.60 3.80 1.4 0.80 2.80
XDKT 11T320SR-R50 ●● ● 6.80 10.60 3.80 2.1 2.00 2.80
-R50 XDKT 11T325SR-R50 ●● 6.80 10.60 3.80 1.6 2.50 2.80
XDKT 11T332SR-R50 ● 6.80 10.60 3.80 1.5 3.20 2.80
XDKT 150508SR-R50 ●● ● ●● 9.30 14.80 5.56 1.6 0.80 4.50
XDKT 150520SR-R50 ●● 9.30 14.80 5.56 1.6 2.00 4.50
XDKT 11T308SR-R60 ● 6.80 10.60 3.80 1.4 0.80 2.80
-R60 XDKT 150508SR-R60 ● 9.30 14.80 5.56 1.6 0.80 4.50

d l s r
CTEP210 TCM10 CTCP220 CTPP225 CTCP230 CTPP235 CTPM225 CTCM235 CTPM240 CTN3105 CTL3215 CTCK215 CTPK220 CTD4205 AMZ H216T CTW4615 CTC5235 CTC5240 CTP6215 l 1 d 1
r
d d 1
15°
l 1
l s

Milling / Shoulder milling
V
C

B12-B18 B111-B112 B21 B257-B266
