VEE-A Square øDh6 R R a p L ød1 S
Non-ferrous

R
S
øDh6

a p
L ød1 ap = Max. depth of cut
S = Connection screw size
Grade Dimensions (in)
Cat. No. No. of Helix Wrench Torque (N•m)
KS15F flutes angle øD ød1 ap R S L
VEE031L20R020AU03S05 ● 0.312 0.300 0.200 0.020 S05 0.390 KEYV-S05 7
VEE037L20R031AU03S06 ● 0.375 0.360 0.230 0.031 S06 0.510 KEYV-S06
VEE037L20R062AU03S06 ● 0.375 0.360 0.230 0.062 10
VEE050L31R031AU03S08 ● 0.500 0.480 0.310 0.031
S
VEE050L31R062AU03S08 ● 0.500 0.480 0.310 0.062
VEE050L31R094AU03S08 ● 0.500 0.480 0.310 0.094 S08 0.650 KEYV-S08 15
5°
VEE050L31R125AU03S08 ● øDe8 0.500 0.480 0.310 0.125
VEE062L39R000AU03S10 ● 0.625 0.600 0.390 0.000
a
VEE062L39R031AU03S10 ● R, C 3 p 45° 0.625 0.600 0.390 0.031
ød1
VEE062L39R062AU03S10 ● L 0.625 0.600 0.390 0.062 S10 0.810 KEYV-S10
VEE062L39R094AU03S10 ● 0.625 0.600 0.390 0.094
VEE062L39R125AU03S10 ● 0.625 0.600 0.390 0.125
VEE075L47R062AU03S12 ● C 0.750 0.720 0.470 0.062 28
S
VEE075L47R094AU03S12 ● 0.750 0.720 0.470 0.094 1.000
α
VEE075L47R125AU03S12 ● 0.750 0.720 0.470 0.125 S12 KEYV-S12
øDe9
VEE075L50R008AU03S12 ● 0.750 0.720 0.500 0.008
VEE075L50R020AU03S12 ● 0.750 0.720 0.500 0.020 1.000
a p ● For non-ferrous metals
L ød1
Interchangable solid carbide heads

VEE-I Square Hard
Steel Stainless Cast Iron Superalloys Materials
10

C S α1 α2
øDe8
Endmills R, C a p ød1 α2 α1

L
ap = Max. depth of cut
α1 = α2
S = Connection screw size
Grade Dimensions (in)
Cat. No. No. of Helix Wrench Torque (N•m)
AH725 flutes angle øD ød1 ap C S L
VEE031L20C012IU04S05 ● 0.312 0.300 0.200 0.012 S05 0.390 KEYV-S05 7
VEE037L27C016IU04S06 ● 4 0.375 0.370 0.270 0.016 S06 0.510 KEYV-S06 10
VEE050L37C020IU04S08 ● 38° 0.500 0.480 0.370 0.020 S08 0.650 KEYV-S08 15
VEE062L47C024IU04S10 ● 5 0.625 0.600 0.470 0.024 S10 0.810 KEYV-S10 28
VEE075L62C024IU04S12 ● 6 0.750 0.720 0.620 0.024 S12 1.000 KEYV-S12 28
● Chamfered corner style endmills

d : Stocked items / Package Quantity = 2 pcs.

10–8 Relating Cutting Conditions Technical reference
pages
(10-23)
(14-1)
