Interchangable solid carbide heads
VED / VEE Square Cont’d Steel Stainless Cast Iron Superalloys Materials
Hard

Grade Dimensions (in) Torque
Cat. No. No. of Helix Wrench
AH725 flutes angle øD ød1 ap R S L (N•m)
VED050L37R015-U04S08 ● 30° 0.500 0.453 0.374 0.015 S08
VED050L37R031-U04S08 ● 30° 0.500 0.453 0.374 0.031 S08
VEE050L37R000-U04S08 ● 45° 0.500 0.453 0.374 0.000 S08
VEE050L37R015-U04S08 ● 45° 0.500 0.453 0.374 0.015 S08 0.650
VEE050L37R031-U04S08 ● 45° 0.500 0.453 0.374 0.031 S08
VEE050L37R062-U04S08 ● 45° 0.500 0.453 0.374 0.062 S08
VED062L47R015-U04S10 ● 30° 0.625 0.600 0.470 0.015 S10 KEYV-S10 28
VED062L47R031-U04S10 ● 30° 0.625 0.600 0.470 0.031 S10
VED062L47R062-U04S10 ● 30° 0.625 0.600 0.470 0.062 S10 0.810
VEE062L47R000-U04S10 ● 45° 0.625 0.600 0.470 0.000 S10
VEE062L47R031-U04S10 ● 4 45° 0.625 0.600 0.470 0.031 S10
VED075L62R015-U04S12 ● 30° 0.750 0.720 0.620 0.015 S12
VED075L62R031-U04S12 ● 30° 0.750 0.720 0.620 0.031 S12
VED075L62R062-U04S12 ● 30° 0.750 0.720 0.620 0.062 S12 1.000
VEE075L62R000-U04S12 ● 45° 0.750 0.720 0.620 0.000 S12 KEYV-S12
VEE075L62R031-U04S12 ● 45° 0.750 0.720 0.620 0.031 S12
VEE100L87R000-U04S15 ★ 45° 1.000 0.957 0.866 0.000 S15
VED100L87R015-U04S15 ★ 30° 1.000 0.957 0.866 0.015 S15 28
VED100L87R031-U04S15 ★ 30° 1.000 0.957 0.866 0.031 S15 1.457 KEYV-S15
VED100L87R062-U04S15 ★ 30° 1.000 0.957 0.866 0.062 S15
VED100L87R125-U04S15 ★ 30° 1.000 0.957 0.866 0.125 S15
★: Available 2015

VED / VEE Square Steel Stainless Cast Iron Superalloys Materials
Hard
10 S

øDe8 5°
Endmills R, C a p L ød1

ap = Max. depth of cut
S = Connection screw size
Grade Dimensions (in)
Cat. No. No. of Helix Wrench Torque
(N•m)
flutes
AH725 AH750 angle øD ød1 ap R C S L
VED031L20R015-U06S05 ● 6 30° 0.312 0.300 0.200 0.015
VEE031L20R000-U06S05 ● 6 45° 0.312 0.300 0.200 0.000 - S05 0.390 KEYV-S05
VEE031L20R031-U06S05 ● 6 45° 0.312 0.300 0.200 0.031 7
VEE031L20C004-U06S05 ● 6 50° 0.312 0.300 0.200 - 0.004
VED037L27R015-U06S06 ● 6 30° 0.375 0.370 0.275 0.015
VED037L27R031-U06S06 ● 6 30° 0.375 0.370 0.275 0.031
VEE037L27R000-U06S06 ● 6 45° 0.375 0.370 0.275 0.000
VEE037L27R015-U06S06 ● 6 45° 0.375 0.370 0.275 0.015 - S06 0.512
VEE037L27R031-U06S06 ● 6 45° 0.375 0.370 0.275 0.031 KEYV-S06 10
VEE037L27R062-U06S06 ● 6 45° 0.375 0.370 0.275 0.062
VEE037L27C004-U06S06 ● C 6 50° 0.375 0.370 0.275 - S 0.004 0.510
VED050L37R015-U06S08 ● 6 30° 0.500 0.453 0.374 0.015 α1 α2
VED050L37R031-U06S08 ● 6 30° 0.500 0.453 0.374 0.031
øDe8
VEE050L37R000-U06S08 ● 6 45° 0.500 0.453 0.374 0.000 ød1
VEE050L37R015-U06S08 ● 6 45° 0.500 0.453 0.374 0.015 - S08 0.650 α1
a
p
α2
R, C
L
VEE050L37R031-U06S08 ● 6 45° 0.500 0.453 0.374 0.031 KEYV-S08 15
VEE050L37R062-U06S08 ● 6 45° 0.500 0.453 0.374 0.062 α1 = α2
VEE050L37C004-U06S08 ● 6 50° 0.500 0.453 0.374 - 0.004
d : Stocked items / Package Quantity = 2 pcs.
