Interchangable solid carbide heads
3 45° 90°
VEE Square No. of Helix Hard
flutes
Steel Stainless Cast Iron Superalloys Materials
R
S
øDh6

a p
L ød1 ap = Max. depth of cut
S = Connection screw size
Grade No. of Helix Dimensions (in)
Cat. No. Wrench
AH725 flutes angle øD ød1 ap R S L
VEE031L20R000-U03S05 ● 0.312 0.300 0.200 0.000 05 0.390 7
VEE037L27R000-U03S06 ● 3 45° 0.375 0.370 0.270 0.000 06 0.512 KEYV-S05 7
VEE050L37R000-U03S08 ● 0.500 0.453 0.370 0.000 08 0.650 7

4 30°/45° 90°
VED / VEESquare No. of Helix Steel Stainless Cast Iron Superalloys Materials
flutes
Hard
R S

øDe8

a p
L ød1 ap = Max. depth of cut
S = Connection screw size
Grade No. of Helix Dimensions (in)
Cat. No. Wrench
AH725 flutes angle øD ød1 ap R S L
VEE025L20R000-U04S05 ● 45° 0.250 0.300 0.200 0.000 05
VED031L20R015-U04S05 ● 30° 0.312 0.300 0.200 0.015 05
VED031L20R031-U04S05 ● 30° 0.312 0.300 0.200 0.031 05 KEYV-S05 7
VED031L20R062-U04S05 ● 30° 0.312 0.300 0.200 0.062 05
VEE031L20R000-U04S05 ● 45° 0.312 0.300 0.200 0.000 05 0.390
VEE031L20R015-U04S05 ● 45° 0.312 0.300 0.200 0.015 05 10
VEE031L20R031-U04S05 ● 45° 0.312 0.300 0.200 0.031 05
VEE031L20R062-U04S05 ● 4 45° 0.312 0.300 0.200 0.062 05 KEYV-S06 10
VED037L27R015-U04S06 ● 30° 0.375 0.370 0.275 0.015 06
VED037L27R031-U04S06 ● 30° 0.375 0.370 0.275 0.031 06 Endmills
VEE037L27R000-U04S06 ● 45° 0.375 0.370 0.275 0.000 06
VEE037L27R015-U04S06 ● 45° 0.375 0.370 0.275 0.015 06 0.512
VEE037L27R031-U04S06 ● 45° 0.375 0.370 0.275 0.031 06 KEYV-S08 15
VEE037L27R062-U04S06 ● 45° 0.375 0.370 0.275 0.062 06
VEE037L47R000-U04S06 ● 45° 0.375 0.370 0.470 0.000 06 0.810

d : Stocked items / Package Quantity = 2 pcs.

Most unmarked items are available on a RFQ basis, contact your sales rep for more information.
Relating Cutting Conditions Technical reference 10–5
pages (10-23) (14-1)
