Chamfering ring (TDXCF Series)

Max. drilling depth L

øDc øDs

Dimensions (in) Max. drilling depth (in)
Cat. No. Stock Application
øDs øDc L Drill dia. drill L/D = 2 L/D = 3 L/D = 4 L/D = 5
øDc
TDXCF280L30 ● 1.059 2.520 1.181
TDXCF290L30 ● 1.098 2.520 1.181 1.125 TDSU1125-* 1.338 2.463 3.588 4.713
TDXCF300L30 ● 1.138 2.520 1.181 1.187 TDSU1187-* 1.456 2.643 3.830 5.017
TDXCF310L30 ● 1.177 2.520 1.181
TDXCF320L30 ● 1.217 2.520 1.181 1.250 TDSU1250-* 1.614 2.864 4.114 5.364
TDXCF330L30 1.252 2.520 1.181
TDXCF340L30 1.291 2.520 1.181 1.312 TDSU1312-* 1.732 3.044 4.356 5.668
TDXCF350L30 1.331 2.520 1.181 1.375 TDSU1375-* 1.889 3.264 4.639 6.014
TDXCF360L30 1.370 3.346 1.181
TDXCF370L30 1.409 3.346 1.181 1.437 TDSU1437-* 2.007 3.444 4.881 6.318
TDXCF380L30 1.449 3.346 1.181 1.500 TDSU1500-* 2.164 3.664 5.164 6.664
TDXCF390L30 1.488 3.346 1.181
TDXCF400L30 1.528 3.346 1.181 1.562 TDSU1562-* 2.322 3.884 5.446 7.008
TDXCF410L30 1.567 3.346 1.181 1.625 TDSU1625-* 2.440 4.065 5.690 7.315
TDXCF420L30 1.598 3.346 1.181
11 TDXCF430L30 1.638 3.346 1.181 1.687 TDSU1687-* 2.598 4.285 5.972 7.659
TDXCF440L30 1.677 3.346 1.181
TDXCF450L30 1.717 3.346 1.181 1.750 TDSU1750-* 2.755 4.505 6.255 8.005
Drilling Tools TDXCF470L30 1.795 3.346 1.181 1.875 TDSU1875-* 3.031 4.906 6.781 8.656
1.181
2.873
3.346
1.756
1.812
8.309
TDXCF460L30
6.497
4.685
TDSU1812-*
3.346
1.181
1.835
TDXCF480L30
TDXCF490L30
1.181
TDXCF500L30 1.874 3.346 1.181 1.937 TDSU1937-* 3.188 5.125 7.062 8.999
1.913
3.346
TDXCF510L30 1.953 3.346 1.181 2.000 TDSU2000-* 3.306 5.306 7.306 9.306
TDXCF520L30 1.992 3.346 1.181
TDXCF530L30 2.031 3.346 1.181
TDXCF540L30 2.071 3.346 1.181
 : Stocked items

11–30 Relating Cutting Conditions Technical reference
