COUNTERSINKS • 3, 4 & 6 Flute
32

Solid Carbide 4 Flute Drill Point Double End Countersinks

Drill & countersink
with 1 tool 60° ANglE 82° ANglE* 90° ANglE
SizE ShANk OvErAll OrDEr PriCE OrDEr PriCE OrDEr PriCE
DiAMETEr lENgTh # EACh # EACh # EACh
1/8" 1/8" 1-1/2" 20-705-008 $28.20 20-705-108 $28.20 20-705-208 $27.12
3/16 3/16 2 20-705-012 35.68 20-705-112 37.12 20-705-212 35.68
Benefits: 1/4 1/4 2 20-705-016 45.23 20-705-116 47.06 20-705-216 45.23
• Save set-up time and tool change time by spot drilling and 5/16 5/16 2-1/2 20-705-020 73.32 20-705-120 73.32 20-705-220 73.32
20-705-224
20-705-024
3/8
3/8
88.49
20-705-124
88.49
85.08
2-1/2
countersinking with the same tool. 1/2 1/2 3 20-705-032 118.61 20-705-132 118.61 20-705-232 118.61
• Increase accuracy and productivity by ensuring concentricity 5/8 5/8 3-1/2 20-705-040 166.36 20-705-140 166.36 20-705-240 166.36
from spot drilling to chamfer/countersinking. 3/4 3/4 4 20-705-048 222.39 20-705-148 222.39 20-705-248 222.39
• 2 cutting edges provide twice the tool life of single end tools. *82° Angle is the most popular angle.
Solid Carbide 6 Flute CNC Precision Single End Countersinks
60° ANglE 82° ANglE* 90° ANglE
ShANk OvErAll OrDEr PriCE OrDEr PriCE OrDEr PriCE
SizE
DiAMETEr lENgTh # EACh # EACh # EACh
1/4" 1/4" 2" 20-705-516 $26.18 20-705-616 $26.18 20-705-716 $26.18
Benefits: 3/8 1/4 2 20-705-524 47.17 20-705-624 47.17 20-705-724 47.17
• Tight dimensions on length and angle 1/2 3/8 2 20-705-532 64.44 20-705-632 64.44 20-705-732 64.44
ensure setting accuracy and repeatability. 5/8 1/2 2-1/4 20-705-540 91.30 20-705-640 91.30 20-705-740 91.30
3/4 1/2 2-3/4 20-705-548 122.98 20-705-648 122.98 20-705-748 122.98
APPLiCAtiOns: 1 1/2 2-3/4 20-705-564 204.07 20-705-664 204.07 20-705-764 204.07
• Use on CNC and preset machines. *82° Angle is the most popular angle.
Carbide Threaded Shank 3 Flute Micro Stop Countersinks
PilOT SizE
iNCluDED _3/32"_ _1/8"_ _5/32"_ _3/16"_ _1/4"__ _5/16"_ PriCE
ANglE OrDEr # OrDEr # OrDEr # OrDEr # OrDEr # OrDEr # EACh
3/8" BODy DiAMETEr
82° — 20-704-504 — — — — $58.40
90° 20-704-501 — — — — — 58.40
100° 20-704-502 — — 20-704-514 — — 58.40
130° — — — 20-704-515 — — 58.40
7/16" BODy DiAMETEr
100° — — 20-704-526 20-704-530 — — $61.54
1/2" BODy DiAMETEr
90° — 20-704-537 — — — — $64.17
100° — 20-704-538 20-704-542 20-704-546 — — 64.17
Benefits: 130° — — — 20-704-547 — — 64.17
• Integral pilot provides greater rigidity in the drilled hole. 5/8" BODy DiAMETEr
• Three flutes eliminate chatter and result in a smooth 82° — — 20-704-556 — 20-704-564 — $67.31
finished surface. 90° 20-704-549 — — — 20-704-565 20-704-569 67.31
• With the use of themicro stop fixture, the countersink 100° 20-704-550 — — — 20-704-566 20-704-570 67.31
depth can be controlled. 130° — — — — 20-704-567 — 67.31
feAtures: PilOT SizE
• 1/4"-28 threaded shank fits standard micro stop cages. iNCluDED __#40__ __#30__ __#20__ __#11__ __#10__ PriCE
ANglE OrDEr # OrDEr # OrDEr # OrDEr # OrDEr # EACh
3/8" BODy DiAMETEr
100° 20-704-600 20-704-601 20-704-603 — — $58.40
Other Sizes & Degrees 1/2" BODy DiAMETEr
Available, Please Call 100° — — — 20-704-614 20-704-615 $64.17
4 Piece Solid Carbide Countersink Sets
Single Flute • 6 Flute • 82° • 90°

Attractive wood case
APPLiCAtiOns: protects your tools.
Single Flute
• Used for non-ferrous materials to include
aluminum, magnesium, brass, bronze,
copper, plastics, acrylic, and wax.
6 Flute iNCluDED OrDEr PriCE
• Chatterlesss geometry for ferrous ANglE # PEr SET
materials to include stainless steels, tool SiNglE FluTE
steels, titanium, and cast iron. 82° 20-704-482 $249.99
90° 20-704-490 249.99
inCLudes: 6 FluTE
• (1) Each 1/4", 1/2", 3/4", 1" countersinks 82° 20-735-682 $249.99
6 Flute 82° Angle • Attractive wood case. 90° 20-735-690 249.99
