Boring Tools • BORING BARS
37

“Micrograin” Mini Solid Carbide Boring Bars

Can be used where standard
boring bars cannot

SHank MiniMuM overall MoDel orDer PriCe
DiaMeTer Bore lengTH # # eaCH APPLICATIONS: FeATureS:
.062" .090" 2" SCB-094 24-570-100 $41.04
.094 .120 2 SCB-125 24-570-102 41.04 • For small hole boring. • CNC qualified.
.125 .150 2 SCB-156 24-570-104 41.58
.156 .180 2 SCB-187 24-570-106 43.12
.187 .240 2-1/2 SCB-250 24-570-108 44.78 ToleranCeS:
.250 .300 2-1/2 SCB-312 24-570-110 47.69 Shank Diameter: ±0.001"
.312 .360 2-1/2 SCB-375 24-570-112 59.94 Minimum Bore: ±0.001"
Solid Carbide Coolant Through Boring Tools For MiniDigi Boring Heads
Series DBM • 8mm Shank Diameter

No reducer
sleeve needed

Other Sizes & Coatings
Available, Please Call
COOlANt thROuGh hOleS ON tOOlS wIth
mINImum BOReS leSS thAN 0.080"

COOlANt GROOve ON tOOlS wIth
MiniMuM MaxiMuM overall MoDel orDer PriCe mINImum BOReS Of 0.080" ANd ABOve
Bore Size Bore DePTH lengTH # # eaCH
D1 l2 l1 BeNeFITS: FeATureS:
.015" (0.38mm) .050" (1.3mm) 1.500" (38mm) DBM-015050 20-998-700 $52.00 • Easy and fast change out of • Coolant through capabilities on all
.020" (0.51mm) .080" (1.9mm) 1.500" (38mm) DBM-020080 20-998-701 52.00 boring tools. sizes of tools.
.025" (0.64mm) .100" (2.5mm) 1.500" (38mm) DBM-025100 20-998-702 52.00 • No reducer sleeves to lose in • Made specifically to be compatible
.030" (0.76mm) .100" (2.5mm) 1.500" (38mm) DBM-030100 20-998-703 47.94 the chip collector. with the Wolhhaupter MiniDigi Boring
.035" (0.89mm) .150" (3.8mm) 1.500" (38mm) DBM-035150 20-998-704 47.94 head for maximum efficiency.
.040" (1.023mm) .200" (5.1mm) 1.500" (38mm) DBM-040200 20-998-705 47.94 APPLICATIONS:
.050" (1.27mm) .250" (6.4mm) 1.500" (38mm) DBM-050250 20-998-706 47.94
.060" (1.52mm) .250" (6.4mm) 1.500" (38mm) DBM-060250 20-998-707 43.58 • Designed to fit the Wolhaupter
.080" (2.03mm) .250" (6.4mm) 1.500" (38mm) DBM-080250 20-998-708 43.58 MiniDigi boring head.
.100" (2.54mm) .250" (6.4mm) 1.500" (38mm) DBM-100250 20-998-709 43.58 • Suitable for all ferrous and
.120" (3.05mm) .400" (10.2mm) 1.500" (38mm) DBM-120400 20-998-710 43.58 non-ferrous materials.
.140" (3.56mm) .500" (12.7mm) 1.500" (38mm) DBM-140500 20-998-711 43.58
.160" (4.06mm) .600" (25.4mm) 2.500" (64mm) DBM-160600 20-998-712 43.58 ToleranCeS:
.180" (4.57mm) .750" (27.9mm) 2.500" (64mm) DBM-180750 20-998-713 43.58 Shank Diameter: -.0025mm (-.0001") /-.0076mm (-.0003")
.200" (5.08mm) .800" (31.8mm) 2.500" (64mm) DBM-200800 20-998-714 43.58 Minimum Bore Diameter: +.000mm (+.000") /-.005" (-0.13mm)
.230" (5.85mm) .800" (31.8mm) 2.500" (64mm) DBM-230800 20-998-715 43.58 Maximum Bore Depth: +.050" (+1.27mm) /-.000" (-.000mm)
.290" (7.37mm) .800" (31.8mm) 2.500" (64mm) DBM-290800 20-998-716 43.58 Overall Length: ±1/64" (±0.40mm)
