GROOVING TOOLS • Retaining Ring
42

Micro-Quik Quick Change Retaining Ring Groove Bars & Toolholders
Change tools in 30
seconds or less

AlTiN Coated Also Available,
Please Call
ToleRanCes:
ReTaininG RinG GRoove BaRs
Shank Diameter: -.0001" / - .0002"
Minimum Bore Diameter: ±.0005"
rETaiNiNg riNg grOOVE Bar QUiCKCHaNgE TOOLHOLDEr rETaiNiNg riNg grOOVE Bar WiTH
QUiCKCHaNgE TOOLHOLDEr Maximum Bore Depth: +.050"
MiCRo-Quik PRoduCTs CoMPaRison:
MiCRo-Quik PRoduCTs CoMPeTiTion
loCkinG sysTeM
Unique “2 Point” Locking/Locating system engineered Single point locking and NOWHERE close
for maximum tool ridigity & centerline repeatability on the ±.0005" (±.001mm) repeatability
within ±.0005" (±.001mm) from tool to tool
Tool ChanGes
Change tools in 30 seconds or less Far MORE TIME & cumbersome
PRoduCT offeRinG
Toolholders: 80 Variations Inch/Metric limited… Mostly offer only 4mm, 6mm & 8mm tools
Job/Application/Machine specific tools, up to 1/2" shanks
PRiCinG
Very competitive Most are more expensive
(Especially with toolholders)
ManufaCTuRinG PRoCess
Made With Exclusive Micro 100 No One Else Has This!
Super Carbide Proprietary Process
ReTaininG RinG GRoove BaRs
MiniMuM hole shank oveRall MaxiMuM GRoove PRojeCTion Model oRdeR PRiCe
diaMeTeR diaMeTeR lenGTh hole dePTh Tool WidTh P # # eaCh
d1 d2 l1 l2 W
.245" 1/4" 2" .250" .030"/.032" .050" QRR-030-4 21-102-312 $38.48
.245" 1/4" 2" .375" .030"/.032" .050" QRR-030-6 21-102-313 38.48
.245" 1/4" 2" .625" .030"/.032" .050" QRR-030-10 21-102-315 38.48
.310" 5/16" 2" .750" .038"/.040" .100" QRR-038-12 21-102-321 47.94
.370" 3/8" 2" .750" .039"/.041" .100" QRR-039-12 21-102-323 62.50
.370" 3/8" 2-1/2" 1.000" .039"/.041" .100" QRR-039-16 21-102-324 62.50
.370" 3/8" 2" .750" .046"/.048" .100" QRR-046-12 21-102-327 62.50
Benefits: .370" 3/8" 2-1/2" 1.250" .046"/.048" .100" QRR-046-20 21-102-329 62.50
Retaining Ring Groove Bars .370" 3/8" 2" .500" .062"/.064" .100" QRR-062-8 21-102-338 62.50
• Elliptical necks for maximum rigidity. .370" 3/8" 2-1/2" 1.000" .062"/.064" .100" QRR-062-16 21-102-340 62.50
Quick Change Holders .370" 3/8" 2-1/2" 1.250" .062"/.064" .100" QRR-062-20 21-102-341 62.50
1.000"
.100"
.069"/.070"
3/8"
.370"
2-1/2"
QRR-069-16 21-102-344
62.50
• Unique “2” point locking/locating system ensures tool to tool .370" 3/8" 2-1/2" 1.250" .069"/.070" .100" QRR-069-20 21-102-345 62.50
change repeatability of ±0.0005" centerline. .370" 3/8" 2" .500" .087"/.089" .100" QRR-087-8 21-102-350 62.50
• Reduce machine set-up, downtime, & tooling costs while .370" 3/8" 2" .750" .087"/.089" .100" QRR-087-12 21-102-351 62.50
boosting productivity. .370" 3/8" 2-1/2" 1.000" .087"/.089" .100" QRR-087-16 21-102-352 62.50
APPLiCAtiOns: .370" 3/8" 2-1/2" 1.250" .087"/.089" .100" QRR-087-20 21-102-353 62.50
2-1/2"
QRR-093-12 21-102-354
.150"
.093"/.095"
87.62
.750"
.495"
1/2"
• Machine aluminum, copper, brass, steels, stainless steels, high .495" 1/2" 2-1/2" 1.000" .125"/.127" .150" QRR-125-16 21-102-363 87.62
temperature alloys, thermoplastics, exotic metals & composites. .495" 1/2" 3" 1.250" .125"/.127" .150" QRR-125-20 21-102-364 87.62
• Great opportunities with Swiss Type Screw Machines. .495" 1/2" 3" 1.500" .125"/.127" .150" QRR-125-24 21-102-365 87.62
• Works exceptionally with the following machines: Tsugami, .495" 1/2" 3" 1.500" .187"/.189" .150" QRR-187-24 21-102-373 87.62
Starr, Okuma, Omni-Turn, Citizens, Tornos, Hass, Hardinge QuiCk ChanGe ToolholdeRs
Conquest & Hardinge Gang
• Also used on small CNC lathes & machining centers. inside ouTside head oveRall Model oRdeR PRiCe
• Excels in many industries including: medical, dental, aerospace, diaMeTeR diaMeTeR diaMeTeR lenGTh # # eaCh
automobile, small pumps and motors, hydraulic fittings and d3 d2 d1 l1
coupling, job shops, machine tool accessories, firearms, heavy 3/16" 1/2" 1/2" 2-3/4" QTH-85 21-102-200 $98.80
2-3/4"
QTH-86
21-102-201
98.80
1/2"
1/2"
1/4"
equipment and repair and wind power maintenance and repair 3/16" 5/8" 5/8" 2-3/4" QTH-105 21-102-202 98.80
feAtures: 1/4" 5/8" 5/8" 2-3/4" QTH-106 21-102-203 98.80
Retaining Ring Groove Bars 5/16" 5/8" 5/8" 2-3/4" QTH-107 21-102-204 98.80
• Uncoated tools featured below. 3/8" 5/8" 5/8" 2-3/4" QTH-108 21-102-205 98.80
QTH-205
3/4"
21-102-206
3/16"
98.80
2-3/4"
3/4"
• Minimum groove width ranges: 0.015" - .250" 1/4" 3/4" 3/4" 2-3/4" QTH-206 21-102-207 98.80
• Maximum groove depth ranges: .250" - 1.500" 5/16" 3/4" 3/4" 2-3/4" QTH-207 21-102-208 98.80
• Shank sizes: 3/16", 1/4", 5/16" & 1/2" 3/8" 3/4" 3/4" 2-3/4" QTH-208 21-102-209 98.80
• Will not chip or break under normal machining conditions. 1/2" 3/4" 3/4" 2-3/4" QTH-210 21-102-210 98.80
• Tools manufactured with the exclusive Micro 100 3/16" 1" 1" 2-3/4" QTH-405 21-102-211 98.80
proprietary process. 1/4" 1" 1" 2-3/4" QTH-406 21-102-212 98.80
Quick Change Toolholders 5/16" 1" 1" 2-3/4" QTH-407 21-102-213 98.80
• Coolant through capabilities. 3/8" 1" 1" 2-3/4" QTH-408 21-102-214 98.80
• Heat treated. 1/2" 1" 1" 2-3/4" QTH-410 21-102-215 98.80
