BORING BARS • Micro-Quik
40

Micro-Quik Quick Change Boring Bars & Toolholders

Change tools in 30
seconds or less
AlTiN Coated Also Available,
Please Call
ToleranCes:
Boring Bars
Shank Diameter: -.0001" / - .0002"
Minimum Bore Diameter: ±.0005"
Maximum Bore Depth: +.050"
MiCro-Quik ProduCTs CoMParison:
MiCro-Quik ProduCTs CoMPeTiTion
boring bar QUiCKCHangE TooLHoLDEr boring bar WiTH
QUiCK CHangE loCking sysTeM
TooLHoLDEr Unique “2 Point” Locking/Locating system engineered Single point locking and NOWHERE close
for maximum tool ridigity & centerline repeatability on the ±.0005" (±.001mm) repeatability
within ±.0005" (±.001mm) from tool to tool
Tool Changes
Change tools in 30 seconds or less Far MORE TIME & cumbersome
ProduCT offering
Toolholders: 80 Variations Inch/Metric limited… Mostly offer only 4mm, 6mm & 8mm tools
Job/Application/Machine specific tools, up to 1/2" shanks
PriCing
Very competitive Most are more expensive
(Especially with toolholders)
ManufaCTuring ProCess
Made with exclusive Micro 100 No One Else Has This!
Super Carbide Proprietary Process
Boring Bars
MiniMuM Bore shank overall MaxiMuM ProjeCTion Model order PriCe
diaMeTer diaMeTer lengTh Bore dePTh P # # eaCh
d1 d2 l1 l2
.050" 3/16" 1-1/2" .150" .013" QBB-050150 21-102-100 $28.86
.050" 3/16" 1-1/2" .400" .013" QBB-050400 21-102-103 28.86
.060" 3/16" 1-1/2" .300" .015" QBB-060300 21-102-106 28.86
.080" 3/16" 1-1/2" .300" .020" QBB-080300 21-102-110 28.86
.100" 3/16" 1-1/2" .300" .025" QBB-100300 21-102-114 30.52
.110" 3/16" 1-1/2" .500" .028" QBB-110500 21-102-118 30.52
.120" 3/16" 1-1/2" .250" .030" QBB-120250 21-102-120 30.52
.120" 3/16" 1-1/2" .350" .030" QBB-120350 21-102-121 30.52
.120" 3/16" 1-1/2" .500" .030" QBB-120500 21-102-122 30.52
.120" 3/16" 2" .800" .030" QBB-120800 21-102-124 30.52
.140" 3/16" 1-1/2" .400" .035" QBB-140400 21-102-125 30.52
.160" 3/16" 1-1/2" .400" .040" QBB-160400 21-102-128 30.52
.160" 3/16" 2" .750" .040" QBB-160750 21-102-130 30.52
.160" 3/16" 2" 1.000" .040" QBB-1601000 21-102-131 30.52
.180" 1/4" 2" .500" .045" QBB-180500 21-102-132 32.97
.180" 1/4" 2" .750" .045" QBB-180750 21-102-133 32.97
.180" 1/4" 2-1/2" 1.000" .045" QBB-1801000 21-102-134 32.97
Benefits: .180" 1/4" 3" 1.500" .045" QBB-1801500 21-102-136 38.69
Boring Bars .200" 1/4" 2" .500" .050" QBB-200500 21-102-137 32.97
21-102-138
QBB-200750
32.97
.200"
2"
.050"
1/4"
.750"
• Elliptical necks for maximum rigidity. .200" 1/4" 2-1/2" 1.200" .050" QBB-2001200 21-102-140 32.97
Quick Change Toolholders .230" 5/16" 2" .500" .058" QBB-230500 21-102-142 44.25
• Unique “2 point” locking/locating system ensures tool to tool .230" 5/16" 2" .750" .058" QBB-230750 21-102-143 44.25
change repeatability of ±0.0005" centerline. .230" 5/16" 2-1/2" 1.000" .058" QBB-2301000 21-102-144 44.25
• Reduce machine set-up, downtime, & tooling costs while .230" 5/16" 3" 1.500" .058" QBB-2301500 21-102-146 50.91
boosting productivity. .320" 3/8" 2-1/2" 1.000" .080" QBB-3201000 21-102-156 60.37
.360" 3/8" 2-1/2" 1.250" .090" QBB-3601250 21-102-164 60.37
APPLiCAtiOns:
• Machine aluminum, copper, brass, steels, stainless steels, high QuiCk Change Toolholders
temperature alloys, thermoplastics, exotic metals and composites. inside ouTside head overall Model order PriCe
• Great opportunities with Swiss Type Screw Machines. diaMeTer diaMeTer diaMeTer lengTh # # eaCh
• Works exceptionally well with the following machines: Tsugami, d3 d2 d1 l1
Starr, Okuma, Omni-Turn, Citizens, Tornos, Hass, 3/16" 1/2" 1/2" 2-3/4" QTH-85 21-102-200 $98.80
21-102-201
98.80
QTH-86
2-3/4"
1/2"
1/4"
1/2"
Hardinge Conquest & Hardinge Gang 3/16" 5/8" 5/8" 2-3/4" QTH-105 21-102-202 98.80
• Also used on small CNC lathes & machining centers. 1/4" 5/8" 5/8" 2-3/4" QTH-106 21-102-203 98.80
• Excels in many industries including: medical, dental, aerospace, 5/16" 5/8" 5/8" 2-3/4" QTH-107 21-102-204 98.80
automobile, small pumps and motors, hydraulic fittings and 3/8" 5/8" 5/8" 2-3/4" QTH-108 21-102-205 98.80
coupling, job shops, machine tool accessories, firearms, heavy 3/16" 3/4" 3/4" 2-3/4" QTH-205 21-102-206 98.80
equipment and repair and wind power maintenance and repair 1/4" 3/4" 3/4" 2-3/4" QTH-206 21-102-207 98.80
5/16" 3/4" 3/4" 2-3/4" QTH-207 21-102-208 98.80
feAtures: 3/8" 3/4" 3/4" 2-3/4" QTH-208 21-102-209 98.80
• Minimum bore ranges: .025" - .490" 1/2" 3/4" 3/4" 2-3/4" QTH-210 21-102-210 98.80
• Maximum bore depth ranges: .050" - 3.500" 3/16" 1" 1" 2-3/4" QTH-405 21-102-211 98.80
• Radii: sharp cornered, .003" - .005" 1/4" 1" 1" 2-3/4" QTH-406 21-102-212 98.80
• Will not chip or break under normal machining conditions. 5/16" 1" 1" 2-3/4" QTH-407 21-102-213 98.80
• Tools manufactured with the exclusive Micro 100 3/8" 1" 1" 2-3/4" QTH-408 21-102-214 98.80
proprietary process. 1/2" 1" 1" 2-3/4" QTH-410 21-102-215 98.80
