END MILLS • Miniature
50

3 Flute Square Solid Carbide Miniature Single End Mills
Uncoated • AlTiN Coated • DLC Coated • Center Cutting •
Regular Length • Stub Length • Long Length & Long Reach
Superb quality at industry
competitive prices

Benefits: feAtures:
• Rigidity and concentricity are key factors in this offering of micro tools. • Made from premium sub micron
• Rushmore offers a complete offering of multiple flute lengths and reaches to help grain carbide.
you achieve the maximum optimization with our tools. • 30° helix angle.
• Excels in hard to reach or deep pocket milling for maximum tool life. • Square end.
APPLiCAtiOns:
• For HRc <48.
• Excels on steels, stainless steels, high temp alloys, cast iron and non-ferrous materials.
AlTiN Coated
• Ideal for high temperature cutting operations in titanium & nickel alloys, stainless steel,
alloy steels & cast iron.
• As machining temperatures increase, the heat is transferred into the chips.
• Tough coating for heavy & interrupted cuts.
DLC Coated
• PVD diamond coating is less expensive
than CVD Diamond. 3 FluTE long rEaCh, long FluTE
• PVD process produces hard, smooth,
hydrogen free diamond like carbon SizE Shank FluTE lEngTh ovErall CoaTing orDEr PriCE
BElow
(DLC) film. DiaMETEr lEngTh Shank lEngTh # EaCh
• A PVD amorphous diamond coating .031" 1/8" 0.156" (5x) 0.31" (10x) 2-1/2" Uncoated 20-532-053 $26.82
which improves lubricity and wear .031" 1/8" 0.156" (5x) 0.31" (10x) 2-1/2" DLC 20-532-050 38.29
resistance in non-ferrous materials. .040" 1/8" 0.2" (5x) 0.4" (10x) 2-1/2" AlTiN 20-532-054 30.42
TolEranCES: • Sharp edges improve results over CVD .047" 1/8" 0.25" (5x) 0.5" (10x) 2-1/2" AlTiN 20-532-055 29.88
Cutting Diameter: in certain abrasive, non-ferrous .062" 1/8" 0.5" (8x) 1" (16x) 2-1/2" Uncoated 20-532-056 26.28
<1/8": +.0005" / -.0005" materials like copper,brass and .062" 1/8" 0.5" (8x) 1" (16x) 2-1/2" DLC 20-532-051 37.72
>1/8": +.002" / -.002" high silicon aluminum. .080" 1/8" 0.75" (9x) 1.25" (15x) 2-1/2" Uncoated 20-532-057 26.28
Flute Length: +.010" / -.000" • Thin coating relative to CVD diamond .100" 1/8" 0.75" (7.5x) 1.25" (12x) 2-1/2" AlTiN 20-532-058 29.88
Length Below Shank: +.010" / -.000"
preventing edge rounding. .125" 1/8" 1" (8x) 1.5" (12x) 2-1/2" DLC 20-532-052 37.72
3 FluTE, long FluTE 3 FluTE, long FluTE
Shank FluTE ovErall orDEr PriCE Shank FluTE ovErall orDEr PriCE
SizE CoaTing SizE CoaTing
DiaMETEr lEngTh lEngTh # EaCh DiaMETEr lEngTh lEngTh # EaCh
.010" 1/8" 0.05" (5x) 2-1/2" Uncoated 20-532-065 $27.99 .060" 1/8" 0.312" (5x) 2-1/2" Uncoated 20-532-088 $18.27
.015" 1/8" 0.078" (5x) 2-1/2" Uncoated 20-532-082 26.01 .060" 1/8" 0.312" (5x) 2-1/2" AlTiN 20-532-089 21.87
.015" 1/8" 0.125" (8x) 2-1/2" Uncoated 20-532-104 44.91 .062" 1/8" 0.312" (5x) 2-1/2" Uncoated 20-532-090 18.27
.015" 1/8" 0.125" (8x) 2-1/2" AlTiN 20-532-105 48.51 .062" 1/8" 0.312" (5x) 2-1/2" AlTiN 20-532-091 21.87
.020" 1/8" 0.1" (5x) 2-1/2" Uncoated 20-532-066 22.32 .062" 1/8" 0.312" (5x) 2-1/2" DLC 20-532-092 29.26
.020" 1/8" 0.1" (5x) 2-1/2" DLC 20-532-067 33.54 .062" 1/8" 0.5" (8x) 2-1/2" Uncoated 20-532-112 20.43
.020" 1/8" 0.16" (8x) 2-1/2" AlTiN 20-532-106 46.53 .062" 1/8" 0.5" (8x) 2-1/2" AlTiN 20-532-113 24.03
.020" 1/8" 0.25" (12x) 2-1/2" Uncoated 20-532-120 53.01 .062" 1/8" 0.75" (12x) 2-1/2" Uncoated 20-532-125 34.92
.025" 1/8" 0.125" (5x) 2-1/2" AlTiN 20-532-068 24.93 .062" 1/8" 0.75" (12x) 2-1/2" AlTiN 20-532-126 38.52
.030" 1/8" 0.15" (5x) 2-1/2" AlTiN 20-532-069 24.12 .062" 1/8" 0.95" (15x) 2-1/2" Uncoated 20-532-130 47.79
.031" 1/8" 0.156" (5x) 2-1/2" Uncoated 20-532-083 20.52 .062" 1/8" 0.625" (10x) 2-1/2" Uncoated 20-532-131 25.65
.031" 1/8" 0.156" (5x) 2-1/2" AlTiN 20-532-084 24.12 .065" 1/8" 0.5" (8x) 2-1/2" AlTiN 20-532-079 24.03
.031" 1/8" 0.25" (8x) 2-1/2" Uncoated 20-532-107 39.78 .070" 1/8" 0.375" (5x) 2-1/2" AlTiN 20-532-093 21.87
.031" 1/8" 0.25" (8x) 2-1/2" AlTiN 20-532-108 43.38 .078" 1/8" 0.406" (5x) 2-1/2" Uncoated 20-532-094 18.27
.031" 1/8" 0.375" (12x) 2-1/2" AlTiN 20-532-121 48.15 .078" 1/8" 0.406" (5x) 2-1/2" AlTiN 20-532-095 21.87
.031" 1/8" 0.375" (12x) 2-1/2" DLC 20-532-122 57.00 .078" 1/8" 0.625" (8x) 2-1/2" Uncoated 20-532-114 20.43
.035" 1/8" 0.175" (5x) 2-1/2" Uncoated 20-532-070 20.52 .078" 1/8" 0.625" (8x) 2-1/2" AlTiN 20-532-115 24.03
.035" 1/8" 0.175" (5x) 2-1/2" AlTiN 20-532-071 24.12 .080" 1/8" 0.406" (5x) 2-1/2" AlTiN 20-532-096 21.87
.040" 1/8" 0.2" (5x) 2-1/2" Uncoated 20-532-072 20.52 .085" 1/8" 0.425" (5x) 2-1/2" AlTiN 20-532-097 21.87
.040" 1/8" 0.2" (5x) 2-1/2" AlTiN 20-532-073 24.12 .090" 1/8" 0.45" (5x) 2-1/2" AlTiN 20-532-098 21.87
.040" 1/8" 0.2" (5x) 2-1/2" DLC 20-532-074 31.64 .093" 1/8" 0.5" (5x) 2-1/2" Uncoated 20-532-099 18.27
.040" 1/8" 0.325" (8x) 2-1/2" Uncoated 20-532-109 39.78 .093" 1/8" 0.5" (5x) 2-1/2" AlTiN 20-532-100 21.87
.045" 1/8" 0.225" (5x) 2-1/2" AlTiN 20-532-075 24.12 .093" 1/8" 0.75" (8x) 2-1/2" Uncoated 20-532-116 20.43
.047" 1/8" 0.25" (5x) 2-1/2" Uncoated 20-532-085 20.52 .093" 1/8" 0.75" (8x) 2-1/2" AlTiN 20-532-117 24.03
.047" 1/8" 0.25" (5x) 2-1/2" AlTiN 20-532-086 24.12 .093" 1/8" 1.125" (12x) 2-1/2" Uncoated 20-532-127 34.92
.047" 1/8" 0.375" (8x) 2-1/2" Uncoated 20-532-110 39.78 .093" 1/8" 1.125" (12x) 2-1/2" AlTiN 20-532-128 38.52
.047" 1/8" 0.375" (8x) 2-1/2" AlTiN 20-532-111 43.38 .100" 1/8" 0.75" (7.5x) 2-1/2" AlTiN 20-532-080 24.03
.047" 1/8" 0.57" (12x) 2-1/2" DLC 20-532-123 53.68 .100" 1/8" 0.75" (7.5x) 2-1/2" DLC 20-532-081 31.54
.047" 1/8" 0.71" (15x) 2-1/2" Uncoated 20-532-129 54.18 .109" 1/8" 0.57" (5x) 2-1/2" Uncoated 20-532-101 18.27
.050" 1/8" 0.3" (6x) 2-1/2" Uncoated 20-532-076 20.52 .118" 1/8" 0.625" (5x) 2-1/2" AlTiN 20-532-102 21.87
.050" 1/8" 0.3" (6x) 2-1/2" AlTiN 20-532-077 24.12 .125" 1/8" 0.625" (5x) 2-1/2" AlTiN 20-532-103 21.69
.055" 1/8" 0.385" (7x) 2-1/2" AlTiN 20-532-078 24.12 .125" 1/8" 1" (8x) 2-1/2" Uncoated 20-532-118 19.17
.055" 1/8" 0.275" (5x) 2-1/2" AlTiN 20-532-087 21.87 .125" 1/8" 1" (8x) 2-1/2" AlTiN 20-532-119 22.77
.055" 1/8" 0.66" (12x) 2-1/2" AlTiN 20-532-124 48.15
