END MILLS • 2 Flute
52

2 Flute Stub Length Solid Carbide Single End Mills
Center Cutting • 30° Helix
Features:
• Micrograin carbide.
• For use in soft materials requiring increased chip expulsion.
• Contain the greatest capacity of flute space for chip carrying capacity.
ToLEranCES: • Great for pocketing and slotting of non-ferrous materials.
Shank Diameter: -.0001" / -.0003"
Cutter Diameter
1/32" thru 1/4": +.000" / -.002" [SeRieS SeM] [SeRieS SeM]
17/64" thru 1/2": +.000" / -.003" SizE Shank FLuTE ovEraLL ordEr PriCE SizE Shank FLuTE ovEraLL ordEr PriCE
TIR Maximum: .005" diaMETEr LEngTh LEngTh # EaCh diaMETEr LEngTh LEngTh # EaCh
1/32" 1/8" 1/16" 1-1/2" 21-100-600 $14.89 5/32" 3/16" 5/16" 1-1/2" 21-100-616 $19.17
End MiLL and FLuTE SELECTion: 3/64 1/8 3/32 1-1/2 21-100-602 14.89 3/16 3/16 3/8 1-1/2 21-100-620 19.17
• It is important to select the end mill not 1/16 1/8 1/8 1-1/2 21-100-604 13.48 1/4 1/4 1/2 2 21-100-628 23.82
only in the appropriate diameter for the 5/64 1/8 5/32 1-1/2 21-100-606 13.48 5/16 5/16 1/2 2 21-100-636 26.38
job but to also choose the correct size 3/32 1/8 3/16 1-1/2 21-100-608 13.48 21/64 3/8 1/2 2 21-100-638 31.50
with the number of flutes most efficient 7/64 1/8 3/16 1-1/2 21-100-610 13.48 3/8 3/8 5/8 2 21-100-644 31.50
for the milling operation. 1/8 1/8 1/4 1-1/2 21-100-612 12.01 1/2 1/2 5/8 2-1/2 21-100-660 51.87
2 Flute “Tuffy” Solid Carbide Stub Length Single End Mills
Common Shank • Center Cutting • 30° Helix
[T12-201]
Shank FLuTE ovEraLL ordEr PriCE
SizE
diaMETEr LEngTh LEngTh # EaCh
1/8" 3/8" 1/4" 2-3/8" 20-205-004 $40.44
5/32 3/8 1/4 2-3/8 20-205-005 40.44
3/16 3/8 5/16 2-3/8 20-205-006 40.44
aPPLICatIONs: Features: 7/32 3/8 5/16 2-3/8 20-205-007 40.44
• Recommended for ferrous materials. • CNC qualified. 1/4 3/8 5/16 2-3/8 20-205-008 40.44
• For slotting and pocketing operations. • Common shank size. 9/32 3/8 7/16 2-1/2 20-205-009 42.53
5/16 3/8 7/16 2-1/2 20-205-010 43.04
3/8 3/8 1/2 2-1/2 20-205-012 47.74
7/16 1/2 5/8 3 20-205-014 76.25
ToLEranCES: 1/2 1/2 5/8 3 20-205-016 72.47
Cutter Diameter: +.001" / -.000" 5/8 5/8 7/8 3-1/4 20-205-020 120.26
Shank Diameter: -.0001" / -.0002" 3/4 3/4 1 3-1/2 20-205-024 178.96
2 Flute Stub Length Solid Carbide Single End Mills
Right Hand Spiral • Right Hand Cutting • Center Cutting •

Lower cost than Uncoated Or TiN Coated • 30° Helix unCoaTEd Tin CoaTEd
regular length Shank FLuTE ovEraLL ordEr PriCE ordEr PriCE
SizE
diaMETEr LEngTh LEngTh # EaCh # EaCh
aPPLICatIONs: 1/16" 1/8" 1/8" 1-1/2" 20-513-304 $8.23 — —
• For milling operations in a variety 3/32 1/8 3/16 1-1/2 20-513-306 8.23 09-338-106 $10.52
20-513-308
7.71 09-338-108
1/4
9.70
1/8
1-1/2
1/8
of materials.
uncoated • For high production milling of slots, 5/32 3/16 5/16 2 2 20-513-310 13.47 09-338-110 17.55
3/16
3/16
10.29 09-338-112
17.02
3/8
20-513-312
pockets, and plunge cuts and similar 1/4 1/4 1/2 2 20-513-316 13.38 09-338-116 17.29
applications for close tolerance work. 5/16 5/16 1/2 2 20-513-320 18.49 09-338-120 23.99
• For a full range of ferrous, non-ferrous 3/8 3/8 5/8 2 20-513-324 22.65 09-338-124 30.68
and non-metallic materials. 7/16 7/16 5/8 2-1/2 20-513-328 40.45 — —
tin coated
• For milling lower strength materials. 1/2 1/2 5/8 2-1/2 20-513-335 44.04 09-338-132 53.35
Offers the maximum flute volume for 5/8 5/8 1 3 20-513-340 77.24 — —
chip removal. 3/4 3/4 1 3 20-513-348 102.99 09-338-148 133.89
2 Flute Stub Length 10% Cobalt Solid Carbide Single End Mills
Right Hand Spiral • Right Hand Cutting • Center Cutting •
Ideal for Uncoated Or TiCN Coated • 40° High Performance Helix
aluminum
aPPLICatIONs:
• For use on ferrous and non-ferrous materials.
• Chip ejection is greatly improved and
allows use of higher feeds and
speeds on stainless steel and unCoaTEd TiCn CoaTEd
uncoated
heat-treated materials. Shank FLuTE ovEraLL ordEr PriCE ordEr PriCE
SizE diaMETEr LEngTh LEngTh # EaCh # EaCh
Features: 1/16" 1/8" 1/8" 1-1/2" 08-600-074 $11.40 — —
• Provides a higher shearing action with 1/8" 1/8" 1/4" 1-1/2" 08-600-076 9.53 — —
superb workpiece finish. 3/16" 3/16" 3/8" 1-1/2" 08-600-078 13.67 — —
tin coated • Higher rake and helix. 1/4" 1/4" 1/2" 2" 08-600-080 16.47 08-601-080 $22.65
• Center cutting to allow for 3 axis 3/8" 3/8" 5/8" 2" 08-600-082 27.80 — —
profile milling, plunging and ramping. 1/2" 1/2" 5/8" 2-1/2" 08-600-084 43.94 — —
