END MILLS • 2 Flute
56

2 Flute SuperCEED Solid Carbide Finishing Single End Mills
®
TiN Or TiCN Coated • Regular Length • Center Cutting • 30° Helix
For Cast Iron
For MoldMakIng
For staInless
For steel
TiN CoaTed
Tin CoaTEd TiCn CoaTEd
Shank lEngTh ovErall ordEr PriCE ordEr PriCE
SizE
diaMETEr oF CuT lEngTh # EaCh # EaCh
1/16" 1/8" 3/16" 1-1/2" 20-104-130 $9.99 20-104-190 $10.26
TiCN CoaTed 3/32 1/8 3/8 1-1/2 20-104-132 9.99 20-104-192 10.26
Features: 1/8 1/8 1/2 1-1/2 20-104-134 9.63 20-104-194 9.84
Heat Generation Reduced Chip Formation Improved 5/32 3/16 9/16 2 2 20-104-136 12.36 20-104-196 12.58
5/8
3/16
3/16
20-104-138
12.67
20-104-198
12.89
• Lower friction. • Lower friction, higher flow speed. 7/32 1/4 5/8 2-1/2 20-104-140 15.21 20-104-200 15.48
• Restricted heat conductivity. • Reduced chip compression and 1/4 1/4 3/4 2-1/2 20-104-142 15.82 20-104-202 16.07
• Reduced thermal impairment of cutting forces. 9/32 5/16 3/4 2-1/2 20-104-144 19.98 20-104-204 20.28
cutting edges. Extension Of Tool Performance 5/16 5/16 13/16 2-1/2 20-104-146 20.61 20-104-206 20.94
• Increased cutting speed. • High hardness protects against 3/8 3/8 1 2-1/2 20-104-148 25.38 20-104-208 25.69
abrasive wear. 7/16 7/16 1 2-3/4 20-104-150 36.26 — —
• High chemical stability prevents built-up 1/2 1/2 1 3 20-104-152 46.49 20-104-212 47.05
TolEranCES: edge, micro cracks and crater wear. 5/8 5/8 1-1/4 3-1/2 20-104-154 87.71 20-104-214 88.27
Cutter Diameter: -.0005" / -.0015" • Increase in tool life. 3/4 3/4 1-1/2 4 20-104-156 130.41 20-104-216 131.37
Shank Diameter: -.0001" / -.0005" • Better surface finish on workpiece. 1 1 1-1/2 4 20-104-158 227.76 20-104-218 229.11
2 Flute Micrograin Solid Carbide Coated Single End Mills
Straight Shank • Square Nose • Right Hand • Spiral Flute • Center Cutting •
TiN Or TiCN Coated • 30° Helix Or 40° High Performance Helix

Features:
TiN CoaTed 30° HeLIX
TiCN Coated - 40° Helix
• Manufactured from 10% cobalt premium micrograin tungsten carbide with
an advanced tool geometry that will outperform conventional end mills.
• Improved chip ejection allowing use of higher feeds and speeds on stainless
TiCN CoaTed 40° HeLIX steel and heat-treated materials.
• For aluminum and non-ferrous materials.
TolEranCES: • Higher rake, helix and shearing action.
Shank Diameter: -.0000" / -.0005" • Center cutting allows for 3 axis profile milling, plunging, ramping and deep
Cutter Diameter slotting applications.
1/32" thru 1/4": +.000" / -.002"
9/32" thru 1": +.000" / -.003"

Tin CoaTEd TiCn CoaTEd Tin CoaTEd TiCn CoaTEd

30° hElix 40° hElix 30° hElix 40° hElix
lEngTh ovErall
lEngTh ovErall
Shank
Shank
SizE diaMETEr oF CuT lEngTh ordEr PriCE ordEr PriCE SizE diaMETEr oF CuT lEngTh ordEr PriCE ordEr PriCE
EaCh
#
#
EaCh
EaCh
#
#
EaCh
1/32" 1/8" 5/64" 1-1/4" 09-338-002 $13.01 — — 15/64" 1/4" 3/4" 2-1/2" — — 08-601-013 $24.41
1/32 1/8 3/32 1-1/2 — — 08-601-000 $15.26 1/4 1/4 3/4 2-1/2 09-338-016 $17.98 08-601-014 22.30
3/64 1/8 7/64 1-1/4 09-338-003 12.91 — — 9/32 5/16 3/4 2-1/2 09-338-018 23.18 — —
3/64 1/8 1/8 1-1/2 — — 08-601-001 16.64 5/16 5/16 13/16 2-1/2 — — 08-601-018 31.89
1/16 1/8 3/16 1-1/2 09-338-004 8.89 08-601-002 13.95 5/16 5/16 13/16 2-1/2 09-338-020 26.21 — —
5/64 1/8 1/4 1-1/2 09-338-005 9.95 — — 3/8 3/8 7/8 2-1/2 09-338-024 30.02 08-601-022 37.77
3/32 1/8 3/8 1-1/2 — — 08-601-004 14.66 7/16 7/16 1 2-3/4 09-338-028 44.22 — —
3/32 1/8 3/8 1-1/2 09-338-006 9.92 — — 1/2 1/2 1 3 09-338-032 52.52 08-601-030 57.39
7/64 1/8 3/8 1-1/2 09-338-007 9.95 — — 5/8 5/8 1-1/4 3-1/2 09-338-040 78.27 — —
1/8 1/8 1/2 1-1/2 09-338-008 8.91 08-601-006 12.59 11/16 11/16 1-1/2 4 09-338-044 137.55 — —
9/64 3/16 9/16 2 — — 08-601-007 18.88 3/4 3/4 1-1/2 4 09-338-048 112.26 08-601-034 164.79
5/32 3/16 9/16 2 — — 08-601-008 18.69
5/32 3/16 9/16 2 09-338-010 13.84 — —
11/64 3/16 9/16 2 — — 08-601-009 19.84
3/16 3/16 5/8 2 09-338-012 13.20 08-601-010 17.62
13/64 1/4 5/8 2-1/2 — — 08-601-011 24.36
7/32 1/4 5/8 2-1/2 09-338-014 19.64 — —
