3 Flute • END MILLS
61

3 Flute Stub Length Solid Carbide Single End Mills
Center Cutting • 30° Helix Features:

NotE: • For use in many soft materials and for many slotting
ENd MiLL aNd FLutE SELECtioN operations in both soft materials and steels.
toLEraNCES: • It is important to select the end mill • Have the same capacity of two flutes, however, the cross
Shank Diameter: -.0001" / -.0003" not only in the appropriate diameter sectional area is larger which provides a greater amount of
Cutter Diameter for the job but to also choose the strength and the ability to slot and pocket
1/32" thru 1/4": +.000" / -.002" correct size with the number of both ferrous and non-ferrous materials.
17/64" thru 1/2": +.000" / -.003" flutes most efficient for the milling Center Cutting
TIR Maximum: .005" operation. • Ramp, plunge or drill into the cut.
[SeRieS SeM] [SeRieS SeM]
ShaNk FLutE ovEraLL ordEr PriCE ShaNk FLutE ovEraLL ordEr PriCE
SizE SizE
diaMEtEr LENgth LENgth # EaCh diaMEtEr LENgth LENgth # EaCh
1/32" 1/8" 1/16" 1-1/2" 21-100-700 $14.89 11/64" 3/16" 5/16" 1-1/2" 21-100-718 $19.17
3/64 1/8 3/32 1-1/2 21-100-702 14.89 3/16 3/16 3/8 1-1/2 21-100-720 19.17
1/16 1/8 1/8 1-1/2 21-100-704 13.48 13/64 1/4 3/8 2 21-100-722 23.82
3/32 1/8 3/16 1-1/2 21-100-708 13.48 1/4 1/4 1/2 2 21-100-728 23.82
1/8 1/8 1/4 1-1/2 21-100-712 12.01 3/8 3/8 5/8 2 21-100-744 31.50
9/64 3/16 1/4 1-1/2 21-100-714 19.17 1/2 1/2 5/8 2-1/2 21-100-760 51.87
5/32 3/16 5/16 1-1/2 21-100-716 19.17
3 Flute Stub Length Micrograin 10% Cobalt Solid Carbide Single End Mills
Center Cutting • Uncoated • 30° Helix Right Hand Spiral

toLEraNCES: BeneFits: Features:
Cutter Diameter • 10% cobalt offers high heat protection. • Improved tool life and
1/64": +.000" / -.001" overall economy.
1/32" thru 1/4": +.000" / -.002" aPPLiCatiOns:
5/16" thru 3/4": +.000" / -.003" • For most general purpose applications.
Shank Diameter: +.0000" / -.0005" • Designed for reduced deflection.

[169] [169]
ShaNk FLutE ovEraLL ordEr PriCE ShaNk FLutE ovEraLL ordEr PriCE
SizE SizE
diaMEtEr LENgth LENgth # EaCh diaMEtEr LENgth LENgth # EaCh
1/64" 1/8" .023" 1-1/2" 20-416-900 $25.34 5/16" 5/16" 1/2" 2" 20-416-949* $29.61
3/64 1/8 3/32 1-1/2 20-416-905* 17.15 3/8 3/8 9/16 2 20-416-955 40.87
1/8 1/8 1/4 1-1/2 20-416-923 14.56 7/16 7/16 5/8 2-1/2 20-416-961 59.97
5/32 3/16 5/16 2 20-416-927 20.94 1/2 1/2 5/8 2-1/2 20-416-965 66.96
1/4 1/4 1/2 2 20-416-943 24.85 *Limited Supply.
ELitE Series 3 Flute Solid Carbide tialN/altiN Coated Single End Mills
Center Cutting • Corner Radius • 35° Helix

Three flutes and high helix for
maximum chip evacuation
[SeRieS S335]
ShaNk FLutE ovEraLL StaNdard ordEr PriCE
SizE
diaMEtEr LENgth LENgth radiuS # EaCh
1/8" 1/8" 1/4" 1-1/2" .008"-.010" 16-061-802 $26.50 aPPLiCatiOns: Features:
3/16" 3/16" 5/16" 2 .008"-.010" 16-061-806 28.50 • For steel, stainless steel, titanium & • Advanced flute geometries.
3/16" 3/16" 9/16" 2 .008"-.010" 16-061-807 31.80 high temp alloys. • Ultra high transverse rupture strength.
1/4" 1/4" 3/8" 2 .015"-.020" 16-061-810 30.70 • Ideal for slotting / pocketing operations. • Standard with corner radius.
1/4" 1/4" 3/4" 2-1/2 .015"-.020" 16-061-811 34.30 • Extra fine grain carbide.
3/8" 3/8" 1/2" 2 .015"-.020" 16-061-818 47.80 toLEraNCES: • Standard with weldon flat.
3/8" 3/8" 1" 2-1/2 .015"-.020" 16-061-819 53.40 Cutting Diameter: +0.000" / -0.002" • TiAlN coating will evolve to AlTiN as
1/2" 1/2" 5/8" 2-1/2 .030"-.035" 16-061-822 73.70 Shank Diameter: -0.0001" / -0.0004" stock rotates.
1/2" 1/2" 1-1/4" 3 .030"-.035" 16-061-823 82.00 Flute Length:
5/8" 5/8" 1-5/8" 3-1/2 .030"-.035" 16-061-825 173.00 1/16" thru 5/16": +.030" / -.000"
3/4" 3/4" 1" 3 .030"-.035" 16-061-826 201.00 21/64" thru 1": +.060" / -.000"
3/4" 3/4" 1-5/8" 4 .030"-.035" 16-061-827 224.00 Overall Length: ±0.060"
