END MILLS • 4 Flute
66

4 Flute Solid Carbide Decimal Micro Single End Mills
10% Cobalt • 1/8” Shank x 1-1/2” Overall Length • Center Cutting • 30° Helix

Super micro-grain carbide
with 10% cobalt

APPLiCAtiOns:
• For aerospace, medical and electronic industries.

TolEranCES:
Other Sizes & Lengths Available,
Please Call Flute Diameter: ±.0005”
TIR:
±.0001”
[ME430] [ME430]
SHank FluTE oVErall orDEr PriCE SHank FluTE oVErall orDEr PriCE
SizE SizE
DiaMETEr lEngTH lEngTH # EaCH DiaMETEr lEngTH lEngTH # EaCH
.010" 1/8" .030" 1-1/2" 16-059-800 $23.00 .047" 1/8" .141" 1-1/2" 16-059-837 $15.50
.015 1/8 .045 1-1/2 16-059-805 20.50 .050 1/8 .150 1-1/2 16-059-840 15.50
.016 1/8 .048 1-1/2 16-059-806 20.50 .051 1/8 .153 1-1/2 16-059-841 15.50
.018 1/8 .054 1-1/2 16-059-808 20.50 .052 1/8 .156 1-1/2 16-059-842 15.50
.020 1/8 .060 1-1/2 16-059-810 20.50 .053 1/8 .159 1-1/2 16-059-843 15.50
.021 1/8 .063 1-1/2 16-059-811 18.00 .055 1/8 .165 1-1/2 16-059-845 15.50
.022 1/8 .066 1-1/2 16-059-812 18.00 .060 1/8 .180 1-1/2 16-059-846 15.50
.023 1/8 .069 1-1/2 16-059-813 18.00 .065 1/8 .195 1-1/2 16-059-847 15.50
.024 1/8 .072 1-1/2 16-059-814 18.00 .075 1/8 .225 1-1/2 16-059-849 15.50
.025 1/8 .075 1-1/2 16-059-815 18.00 .080 1/8 .240 1-1/2 16-059-850 15.50
.027 1/8 .081 1-1/2 16-059-817 18.00 .085 1/8 .255 1-1/2 16-059-851 15.50
.028 1/8 .084 1-1/2 16-059-818 18.00 .090 1/8 .270 1-1/2 16-059-852 15.50
.030 1/8 .090 1-1/2 16-059-820 18.00 .095 1/8 .285 1-1/2 16-059-853 15.50
.031 1/8 .093 1-1/2 16-059-821 15.50 .100 1/8 .300 1-1/2 16-059-854 15.50
.032 1/8 .096 1-1/2 16-059-822 15.50 .105 1/8 .315 1-1/2 16-059-855 15.50
.035 1/8 .105 1-1/2 16-059-825 15.50 .110 1/8 .330 1-1/2 16-059-856 15.50
.040 1/8 .120 1-1/2 16-059-830 15.50 .115 1/8 .345 1-1/2 16-059-857 15.50
.044 1/8 .132 1-1/2 16-059-834 15.50 .120 1/8 .360 1-1/2 16-059-858 15.50
4 Flute Solid Carbide Variable Helix Decimal Single End Mills
Regular Length • Reduced Neck Long Length • 1/8” Shank • Center Cutting

regular length TolEranCES:
Cutting Diameter: +0.0005" / -0.0005"
Shank Diameter: +0.0000" / -0.0003"
reduced neck long length rEgular lEngTH
FluTE oVErall CornEr orDEr PriCE
3 Flutes, Stub Lengths, Extra Long Lengths & SizE lEngTH lEngTH CHaMFEr # EaCH
AlTiN Coated Available, Please Call .031" .093" 1.500" .002"-.004" 20-502-900 $23.40
.047" .141" 1.500" .002"-.004" 20-502-901 23.40
Benefits: feAtures: .062" .186" 1.500" .002"-.004" 20-502-902 21.60
• Progressive geometry reduces • Shank diameter: 1/8"
harmonics and chatter. rEDuCED nECk long lEngTH
• Superior material removal rates. SizE FluTE oVErall CornEr ToTal orDEr PriCE
• Finer surface finishes. lEngTH lEngTH CHaMFEr rEaCH # EaCH
.031" .062" 2.500" .002"-.004" .1870" 20-502-910 $29.30
APPLiCAtiOns: .047" .094" 2.500" .002"-.004" .282" 20-502-911 28.64
• Designed for aerospace materials, .062" .124" 2.500" .002"-.004" .375" 20-502-912 28.64
exotic alloys and difficult to machine .078" .156" 2.500" .002"-.004" .468" 20-502-913 28.64
ferrous & non-ferrous materials. .093" .186" 2.500" .002"-.004" .562" 20-502-914 28.64
• 4 flute for harder materials. .125" .250" 2.500" .002"-.004" .750" 20-502-915 27.98
