END MILLS • 4 Flute
70

4 Flute Micrograin Solid Carbide Single End Mills
Straight Shank • Square Nose • Right Hand • Spiral Flute • Center Cutting • 30° Helix

For Steel

[GEM] [111]
aPPLICatIONs: Shank FluTE ovErall ordEr PriCE ordEr PriCE ordEr PriCE
Rushmore SizE diaMETEr lEngTh lEngTh # EaCh # EaCh # EaCh
• For general purpose use on all materials. 1/64" 1/8" .040" 1-1/2" — — — — 20-411-011 $27.53
Micro 100 1/32 1/8 3/32 1-1/2 20-501-002 $10.82 — — — —
• High performance. 1/32 1/8 5/64 1-1/2 — — 21-100-500 $15.57 — —
M.A. Ford 3/64 1/8 1/8 1-1/2 20-501-003 10.82 — — — —
• For milling ferrous metals. 3/64 1/8 7/64 1-1/2 — — 21-100-502 15.57 — —
1/16 1/8 3/16 1-1/2 20-501-004 9.26 21-100-504 14.26 20-411-063 16.63
Features: 5/64 1/8 3/16 1-1/2 — — 21-100-506 14.26 — —
Micro 100 5/64 1/8 15/64 1-1/2 — — — — 20-411-079 17.02
—
—
• Can attain optimum cutting speeds and 5/64 1/8 1/4 1-1/2 20-501-005 7.47 — — 20-411-091 17.02
—
—
1/8
9/32
3/32
1-1/2
—
—
feeds, maximum rigidity and virtually no 3/32 1/8 3/8 1-1/2 20-501-006 7.47 21-100-508 14.26 — —
tool deflection, allowing for much higher 7/64 1/8 7/64 1-1/2 — — 21-100-510 14.26 — —
metal removal rates & far fewer regrinds. 7/64 1/8 3/8 1-1/2 8.23 — —
M.A. Ford 1/8 1/8 3/8 1-1/2 — — — — 20-411-105 15.92
• Maximum rigidity and feed rates. 1/8 1/8 1/2 1-1/2 20-501-008 6.68 21-100-512 12.69 — —
• Manufactured from 10% cobalt premium 9/64 3/16 1/2 2 — — 21-100-514 20.11 — —
micrograin tungsten carbide with 5/32 3/16 1/2 2 — — — — 20-411-113 22.65
an advanced tool geometry that will 5/32 3/16 9/16 2 20-501-010 10.45 21-100-516 20.11 — —
outperform conventional end mills. 11/64 3/16 5/8 2 — — 21-100-518 20.11 — —
3/16 3/16 9/16 2 — — — — 20-411-119 22.17
3/16 3/16 5/8 2 20-501-012 10.29 21-100-520 20.11 — —
13/64 1/4 5/8 2-1/2 — — 21-100-522 25.13 — —
7/32 1/4 5/8 2-1/2 20-501-014 14.41 21-100-524 25.13 20-411-125 29.37
1/4 1/4 3/4 2-1/2 20-501-016 13.13 21-100-528 25.13 20-411-129 27.05
9/32 5/16 7/8 2-1/2 20-501-018 21.41 — — — —
5/16 5/16 7/8 2-1/2 20-501-020 20.34 21-100-532 29.25 20-411-135 37.10
TolEranCES: 3/8 3/8 7/8 2-1/2 — — 21-100-534 33.17 — —
Cutter Diameter 3/8 3/8 7/8 2-1/2 20-501-024 24.71 — — 20-411-141 40.40
1/32" thru 1/4": +.000" / -.002" 7/16 7/16 1 2-1/2 — — 21-100-536 52.34 — —
9/32" thru 1": +.000" / -.003" 7/16 7/16 7/8 2-1/2 20-501-028 32.43 — — 20-411-147 57.51
TIR Maximum: .005" 1/2 1/2 1 3 20-501-032 40.94 21-100-538 57.62 20-411-151 67.32
ruShMorE 9/16 9/16 1-1/8 3-1/2 — — — — 20-411-155 128.52
Shank Diameter: -.0001" / -.0004" 9/16 9/16 1-1/4 3-1/2 20-501-036 71.06 21-100-540 88.44 — —
MiCro 100 5/8 5/8 1-1/4 3-1/2 20-501-040 73.12 21-100-542 101.71 — —
Shank Diameter: -.0001" / -.0003" 11/16 3/4 1-1/2 4 20-501-044 119.47 — — — —
M.a. Ford 3/4 3/4 1-1/2 4 20-501-048 113.29 21-100-546 154.99 20-411-163 159.99
Shank Diameter: +.0000" / -.0005" 7/8 7/8 1-1/2 4 20-501-056 164.79 21-100-548 214.81 — —
1/64" Cutter Diameter: +.000" / -.001" 1 1 1-1/2 4 20-501-064 172.00 21-100-550 234.81 — —
7 Piece Micrograin Solid Carbide Single End Mill Sets
4 Flute • Uncoated Or TiN Coated • Inch Or Metric Sets • Center Cutting • 30° Helix
aPPLICatIONs: Features:
• For use with all materials. • Popular sizes stored in convenient & attractive wooden case.
• Stay organized & prepared.
ModEl ordEr PriCE
CoaTing dESCriPTion
# # PEr SET
inCh SizES Sizes 1/16", 1/8", 3/16", 1/4", 5/16", 3/8", 1/2" & fitted wooden case
Uncoated Right Hand Spiral, Square Nose S1501 20-501-900 $140.07
TiN Coated Right Hand Spiral, Square Nose S1501-TiN 09-337-100 195.69
METriC SizES Sizes 3, 4, 5, 6, 8, 10, 12mm & fitted wooden case
Uncoated Right Hand Spiral, Square Nose S1501-M 20-501-901 $221.44
Model #S1501
