4 Flute • END MILLS
73

4 Flute SuperCEED Solid Carbide Coated Finishing Single End Mills
®
TiN Or TiCN Coated • Regular Length • Center Cutting • 30° Helix
Features:
Heat Generation Reduced • High chemical stability prevents • TiN allows higher lubricity for freer
• Lower friction. built-up edge, micro cracks and chip flow, reducing build-up edge
• Restricted heat conductivity. crater wear. formation and cratering - great
• Increased cutting speed. • Increase in tool life. for general purpose use.
Chip Formation Improved TiN (Titanium Nitride) • On non-ferrous materials there
• Lower friction, higher flow speed. • This treatment will provide heat is a tendency to gall so please TiN coatED
• Reduced chip compression/ resistance and extreme hardness to use caution.
cutting forces. allow the tool to run at higher feeds • TiN also requires an increase
Extension Of Tool Performance and speeds. of 25% to 30% in machining
• High hardness protects against speeds vs. uncoated tools.
abrasive wear. For steel TiCN (Titanium Carbonitride) TicN coatED
Tin CoaTEd TiCn CoaTEd • When under conditions of moderate
Shank lEngTh ovErall ordEr PriCE ordEr PriCE cutting temperatures, TiCN provides
SizE
diaMETEr oF CUT lEngTh # EaCh # EaCh harder and more wear resistant
1/16" 1/8" 3/16" 1-1/2" 20-101-130 $11.02 20-101-190 $11.02 than TiN.
3/32 1/8 3/8 1-1/2 20-101-132 11.02 20-101-192 11.02 • It also provides 50% more spindle
1/8 1/8 1/2 1-1/2 20-101-134 10.05 20-101-194 10.05 speed compared to TiN, especially
5/32 3/16 9/16 2 20-101-136 14.87 20-101-196 14.87 in stainless steels.
3/16 3/16 5/8 2 20-101-138 13.78 20-101-198 13.78 • There is a tendency to gall on
7/32 1/4 5/8 2-1/2 20-101-140 18.62 20-101-200 18.62 non-ferrous materials so please
1/4 1/4 3/4 2-1/2 20-101-142 15.41 20-101-202 15.41
9/32 5/16 3/4 2-1/2 20-101-144 22.23 20-101-204 22.23 use caution.
5/16 5/16 13/16 2-1/2 20-101-146 23.05 20-101-206 23.05 • TiCN also requires an increase
3/8 3/8 1 2-1/2 20-101-148 29.22 20-101-208 29.22 of 35% to 50% in machining
7/16 7/16 1 2-3/4 20-101-150 36.07 20-101-210 36.07 speeds vs. uncoated tools.
1/2 1/2 1 3 20-101-152 47.34 20-101-212 47.34
5/8 5/8 1-1/4 3-1/2 20-101-154 91.29 20-101-214 91.29 TolEranCES:
3/4 3/4 1-1/2 4 20-101-156 133.96 20-101-216 133.96 Cutter Diameter: -.0005" / -.0015" ♦ See Page Below For
1 1 1-1/2 4 20-101-158 200.11 20-101-218 200.11 Shank Diameter: -.0001" / -.0005" SuperCEED Information.
4 Flute SuperCEED Solid Carbide -MAX Coated Ultra Fine
®
®
Micrograin Carbide Single End Mills
Right Hand • Regular Length • Center Cutting • 30° Helix
Shank FlUTE ovErall ordEr PriCE Unique coating provides
SizE super lubricity
diaMETEr lEngTh lEngTh # EaCh
1/16" 1/8" 3/16" 1-1/2" 20-101-004 $16.73
1/8 1/8 1/2 1-1/2 20-101-008 16.73
3/16 3/16 5/8 2 20-101-012 18.73 Features:
1/4 1/4 3/4 2-1/2 20-101-016 22.79
5/16 5/16 13/16 2-1/2 20-101-020 32.96 • High temperature and titanium alloys,
3/8 3/8 1 2-1/2 20-101-024 39.01 machining wet, dry, or semi-dry condition.
1/2 1/2 1 3 20-101-032 62.22 • Hardened workpieces, steel, cast iron,
5/8 5/8 1-1/4 3-1/2 20-101-040 113.33 stainless, and nickel based alloys. TolEranCES:
3/4 3/4 1-1/2 4 20-101-048 160.25 • High hardness, enhanced toughness, Cutter Diameter: 0" / -.0012"
1 1 1-1/2 4 20-101-064 269.38 high heat resistance. Shank Diameter: -.000" / -.0003"

4 Piece 4 Flute Superceed Solid Carbide Coated Single End Mill Sets
®
Center Cutting • Regular Length • TiN Coated • -MAX Coated • 30° Helix
®
Buy set aPPLICatIONs:
and save! TiN Coated
• For general purpose & longer tool life.
♦ See Above For SuperCEED And For Cast Iron X-MAX Coated
®

X-MAX Coating Information. For HIgH temp • For high temperature & titanium TiN SEt
®

exotIC alloys alloys, machining wet, dry or
For moldmakIng semi-dry conditions.
For staInless • Performs well on hardened
For steel For steel workpieces, steel, cast iron, stainless
ordEr PriCE ordEr PriCE & nickel based alloys.
CoaTing CoaTing
# PEr SET # PEr SET INCLudes:
TiN Coated 20-101-169 $85.26 X-MAX ® 20-101-069 $130.96 • (1) Each of the following sizes:
1/8”, 1/4”, 3/8”, & 1/2” X-MaX ® SEt
