4 Flute • END MILLS
69

4 Flute Micrograin Solid Carbide Single End Mills
Straight Shank • Square Nose • Right Hand • Spiral Flute •
Center Cutting • 40° Helix

APPLiCAtiOns: feAtures:
• Center cutting style allows for 3 axis profile milling, plunging and ramping. • Manufactured from 10% cobalt premium micrograin
• For profiling, slotting of stainless steel and exotic materials. tungsten carbide with an advanced tool geometry that
will outperform conventional end mills.
ShANk FluTE ovErAll orDEr PriCE ShANk FluTE ovErAll orDEr PriCE
SizE SizE • 40° helix provides a higher shearing action with superb
DiAMETEr lENgTh lENgTh # EACh DiAMETEr lENgTh lENgTh # EACh workpiece finish.
3/64" 1/8" 7/64" 1-1/2" 08-600-038 $14.29 15/64" 1/4" 3/4" 2-1/2" 08-600-050 $17.37 • Chip ejection is improved, allowing higher feeds and
1/16 1/8 1/4 1-1/2 08-600-039 13.24 1/4 1/4 3/4 2-1/2 08-600-051 18.41 speeds on stainless steel and heat-treated materials.
5/64 1/8 3/16 1-1/2 08-600-040 13.74 17/64 5/16 3/4 2-1/2 08-600-052 30.08 • Higher rake and helix.
3/32 1/8 9/32 1-1/2 08-600-041 13.24 5/16 5/16 13/16 2-1/2 08-600-055 28.83
7/64 1/8 3/8 1-1/2 08-600-042 14.39 11/32 3/8 7/8 2-1/2 08-600-057 31.77
1/8 1/8 1/2 1-1/2 08-600-043 10.31 3/8 3/8 1 2-1/2 08-600-059 31.36
9/64 3/16 1/2 2 08-600-044 16.14 13/32 7/16 1 2-3/4 08-600-061 51.89 TolErANCES:
5/32 3/16 1/2 2 08-600-045 15.90 27/64 7/16 1 2-3/4 08-600-062 53.06 Cutter Diameter
11/64 3/16 5/8 2 08-600-046 15.90 29/64 1/2 1 3 08-600-064 63.52 1/32" thru 1/4": +.000" / -.002"
3/16 3/16 5/8 2 08-600-047 14.32 1/2 1/2 1 3 08-600-067 48.37 9/32" thru 1": +.000" / -.003"
13/64 1/4 5/8 2-1/2 08-600-048 23.14 5/8 5/8 1-1/4 3-1/2 08-600-069 92.69 TIR Maximum: .005"
7/32 1/4 5/8 2-1/2 08-600-049 19.24 3/4 3/4 1-1/2 4 08-600-071 144.19 Shank Diameter: -.0001" / -.0004"
4 Flute Micrograin Solid Carbide TiCN Coated Single End Mills
Straight Shank • Square Nose • Right Hand • Spiral Flute • Center Cutting •
40° High Performance Helix

Coatings allow higher speed and feed rates, offering
extended tool life and increased lubricity
APPLiCAtiOns: feAtures:
• Center cutting style allows for 3 axis profile milling, plunging and ramping. • Manufactured from 10% cobalt premium micrograin
• For profiling, slotting of stainless steel and exotic materials. tungsten carbide with an advanced tool geometry that
will outperform conventional end mills.
FluTE ovErAll
FluTE ovErAll
ShANk
ShANk
SizE DiAMETEr lENgTh lENgTh orDEr PriCE SizE DiAMETEr lENgTh lENgTh orDEr PriCE • 40° helix provides a higher shearing action with superb
#
EACh
EACh
#
1/32" 1/8" 3/32" 1-1/2" 08-601-037 $14.81 17/64" 5/16" 3/4" 2-1/2" 08-601-052 $36.67 workpiece finish.
3/64 1/8 1/8 1-1/2 08-601-038 15.36 9/32 5/16 3/4 2-1/2 08-601-053 36.04 • Chip ejection is greatly improved and allows use of
1/16 1/8 3/16 1-1/2 08-601-039 13.54 5/16 5/16 13/16 2-1/2 08-601-055 45.72 higher feeds and speeds on stainless steel and heat-
5/64 1/8 3/16 1-1/2 08-601-040 13.67 21/64 3/8 7/8 2-1/2 08-601-056 40.16 treated materials.
3/32 1/8 3/8 1-1/2 08-601-041 13.54 11/32 3/8 7/8 2-1/2 08-601-057 40.16 • Higher rake and helix.
1/8 1/8 1/2 1-1/2 08-601-043 12.57 3/8 3/8 1 2-1/2 08-601-059 38.25
9/64 3/16 9/16 2 08-601-044 19.56 13/32 7/16 1 2-3/4 08-601-061 59.67
5/32 3/16 9/16 2 08-601-045 20.16 7/16 7/16 1 2-3/4 08-601-063 48.81
11/64 3/16 9/16 2 08-601-046 20.03 1/2 1/2 1 3 08-601-067 59.00 TolErANCES:
3/16 3/16 5/8 2 08-601-047 17.45 9/16 9/16 1-1/4 3-1/2 08-601-068 105.75 Shank Diameter: -.0000" / -.0004"
13/64 1/4 5/8 2-1/2 08-601-048 28.23 5/8 5/8 1-1/4 3-1/2 08-601-069 113.29 Cutter Diameter
7/32 1/4 5/8 2-1/2 08-601-049 23.45 3/4 3/4 1-1/2 4 08-601-071 169.94 1/32" thru 1/4": +.000" / -.002"
15/64 1/4 3/4 2-1/2 08-601-050 21.19 1 1 1-1/2 4 08-601-073 267.79 9/32" thru 1": +.000" / -.003"
1/4 1/4 3/4 2-1/2 08-601-051 22.44 TIR Maximum: .005"
4 Flute AlTiN Coated Solid Carbide Single End Mills
Center Cutting • 40° Helix
Benefits: APPLiCAtiOns: High shearing action with
• Provide a higher rake and helix angle than • Used in many different materials but are best suited for rapid chip evacuation
conventional end mills. aggressive machining of aircraft/aerospace materials,
• High shearing action provides excellent chip stainless steels, high-alloy carbon steels, nickel-based
evacuation and enables highly efficient cutting. high-temp alloys and titanium alloys.
• Can be used in almost all materials depending • Excels in mold applications, removing more material
upon the application. faster than ball end mills.
• Performs exceptionally well in profiling, slotting
and plunging.
ShANk
ovErAll
ShANk
FluTE
FluTE
ovErAll
SizE DiAMETEr lENgTh lENgTh orDEr PriCE SizE DiAMETEr lENgTh lENgTh orDEr PriCE
D1 D2 l2 l1 # EACh D1 D2 l2 l1 # EACh
1/32" 1/8" 3/32" 1-1/2" 28-500-020 $15.95 1/4" 1/4" 3/4" 2-1/2" 28-500-036 $23.68
1/16" 1/8" 3/16" 1-1/2" 28-500-022 13.63 5/16" 5/16" 13/16" 2-1/2" 28-500-038 37.07
3/32" 1/8" 3/8" 1-1/2" 28-500-024 13.68 3/8" 3/8" 1" 2-1/2" 28-500-040 44.28
1/8" 1/8" 1/2" 1-1/2" 28-500-026 12.86 7/16" 7/16" 1" 2-3/4" 28-500-042 53.77 TolErANCES:
9/64" 3/16" 9/16" 2" 28-500-028 20.07 1/2" 1/2" 1" 3" 28-500-044 62.29 Cutting Diameter
5/32" 3/16" 9/16" 2" 28-500-030 20.07 5/8" 5/8" 1-1/4" 3-1/2" 28-500-046 113.29 1/32" thru 3/32": +.0005" / -.0005"
3/16" 3/16" 5/8" 2" 28-500-032 18.53 3/4" 3/4" 1-1/2" 4" 28-500-048 175.09 1/8" thru 3/4": +.000" / -.002"
7/32" 1/4" 5/8" 2-1/2" 28-500-034 25.22 Shank Diameter: +.0000" / -.0003"
