END MILLS • 2 Flute
60

2 Flute SuperCEED Carbide Diamond Coated Single End Mills
®
Center Cutting • Regular Length • 30° Helix

Excels on
graphite
APPLICATIONS: FeATureS:
• For high speed cutting. • Diamond coating, a hardness SHank FluTE ovErall orDEr PrICE
• For graphite and non-ferrous non-metallic layer, improves tool life. SIZE DIaMETEr lEngTH lEngTH # EaCH
materials such as plastics, thermoplastics, etc. 1/8" 1/8" 9/16" 2" 20-102-008 $42.89
• Ultra fine film diamond coated carbide end mills 3/16 3/16 3/4 2 20-102-012 45.37
ensure smooth and excellent surface on work materials. 1/4 1/4 13/16 2-3/4 20-102-016 61.37
5/16 5/16 7/8 2-3/4 20-102-020 68.02
TolEranCES: 3/8 3/8 1 3 20-102-024 84.88
Shank Diameter: +.0000" / -.0003" 1/2 1/2 1 3 20-102-032 129.88
ElITE Series 2 Flute 45° Helix TiCn Coated Solid Carbide
High Performance Single End Mills For aluminum
Center Cutting [SERIES A245]
SHank FluTE ovErall orDEr PrICE
SIZE
DIaMETEr lEngTH lEngTH # EaCH
1/8" 1/8" 1/4" 1-1/2" 16-061-442 $19.70
1/8 1/8 3/8 1-1/2 16-061-443 21.00
APPLICATIONS: 3/16 3/16 5/16 2 16-061-446 25.90
• High performance milling of aluminum. 3/16 3/16 9/16 2 16-061-447 28.90
• Ideal for slotting and pocketing 1/4 1/4 3/8 2-1/2 16-061-450 35.40
TolEranCES: applications. 1/4 1/4 3/4 2-1/2 16-061-451 39.20
Shank Diameter: -.0001" / -.0004" FeATureS: 1/4 1/4 1-1/4 4 16-061-452 61.10
Cutting Diameter: +.000" / -.002" 5/16 5/16 13/16 2-1/2 16-061-456 42.40
Flute Length • Niagara Microshield TiCN coating. 3/8 3/8 1 2-1/2 16-061-462 49.30
1/16" thru 5/16": +.030" / -.000" • Eccentric primary with cylindrical land. 1/2 1/2 1-1/4 3 16-061-471 79.70
21/64" thru 1": +.060 / -.000" Other Sizes & Coatings 5/8 5/8 1-5/8 3-1/2 16-061-475 151.00
Overall Length: ±.060" Available, Please Call 3/4 3/4 1-5/8 4 16-061-479 209.00
2 Flute 40° Helix Solid Carbide Zrn Coated Single End Mills For aluminum
Stub Length • Regular Length • Long Length • Center Cutting
[SERIES 108]
SHank FluTE ovErall orDEr PrICE
SIZE
DIaMETEr lEngTH lEngTH # EaCH
1/8" 1/8" 3/8" 1-1/2" 20-432-200 $14.88
1/8" 1/8" 1/4" 1-1/2" 20-432-202 14.58
APPLICATIONS: 5/32" 3/16" 9/16" 2" 20-432-204 20.05
• Designed to be a workhorse 3/16" 3/16" 9/16" 2" 20-432-206 20.01
in milling aluminum and other 1/4" 1/4" 3/4" 2-1/2" 20-432-208 28.09
non-ferrous materials. 1/4" 1/4" 1-1/4" 3-1/2" 20-432-210 36.73
Other Diameters & Lengths 3/8" 3/8" 1" 2-1/2" 20-432-212 37.63
Also Available, Please Call 1/2" 1/2" 1-1/4" 3" 20-432-214 52.12
TolEranCES: 1/2" 1/2" 2" 4" 20-432-216 81.04
Shank Diameter: -.0001" / -.0004" 3/8" thru 1" Coolant Slots & 1/2" 1/2" 3" 6" 20-432-218 113.22
Cutting Diameter Set Screw Flats Available Upon 5/8" 5/8" 1-5/8" 3-1/2" 20-432-220 97.33
1/8" thru 1": +.000" / -.002" Request, Please Call 3/4" 3/4" 1-5/8" 4" 20-432-222 128.71
3 Flute Solid Carbide Tapered Square End Single End Mills
Center Cutting

Provides a world-class
workpiece finish
TolEranCES:
BeNeFITS: APPLICATIONS: Cutting Diameter: +.000" / -.002"
• Compared to high speed steel or cobalt tool, improved • A staple in aerospace, Shank Diameter: h6
surface finishes, increased through-put and decreased mold-making and die-
“cost per part” in a broad range of materials ranging from cast industries, tapered
FluTE
SHank
heat resistant alloys, tool & die alloys, to cast irons and endmills are indispensable CEnTErlInE SMall EnD lEngTH DIaMETEr ovErall orDEr PrICE
DIaMETEr
lEngTH
EaCH
#
anglE
non-ferrous materials. for slotting & side-milling. 5º 1/8" 3/4" 1/4" 3" 20-109-250 $35.00
• Avoids the task of re-orienting either the milling head or 7º 1/8" 1/2" 1/4" 3" 20-109-251 35.00
workpiece in order to provide a qualified workpiece taper. FeATureS: 10º 3/32" 1/2" 1/4" 3" 20-109-252 35.00
• Rigorous manufacturing standards insure consistent • h6 slip-fit shank tolerances. 5º 1/8" 1-1/2" 3/8" 3-1/2" 20-109-253 49.25
quality tool-to-tool. • Cylindrical shanks are 7º 1/8" 3/4" 3/8" 3-1/2" 20-109-254 49.25
• 3 fluted tool is the perfect combination for chip clearance shrink-fit capable. 10º 1/8" 3/4" 3/8" 3-1/2" 20-109-255 49.25
and surface finishes in a wide variety of materials. 5º 1/4" 1-1/4" 1/2" 4" 20-109-256 64.81
• World-class fluting finishes insure excellent chip 7º 3/16" 1-1/4" 1/2" 4" 20-109-257 64.81
evacuation and resistance to built up edge. 10º 1/8" 1" 1/2" 4" 20-109-258 64.81
