2 Flute • END MILLS
53

2 Flute SuperCEED Solid Carbide Coated Ultra Fine Micrograin
®
Carbide Finishing Stub Length Single End Mills
TiN Or TiCN Coated • Center Cutting • 30° Helix

FeATureS:
Heat Generation Reduced
• Lower friction. tiN coatED
Tin CoaTEd TiCn CoaTEd • Restricted heat conductivity.
Shank LEngTh ovEraLL ordEr PriCE ordEr PriCE
SizE • Reduced thermal impairment of
diaMETEr oF CUT LEngTh # EaCh # EaCh cutting edges.
1/16" 1/8" 1/8" 1-1/2" 20-104-100 $9.23 20-104-160 $9.48 • Increased cutting speed.
3/32 1/8 3/16 1-1/2 20-104-102 9.23 20-104-162 9.48 Chip Formation Improved
1/8 1/8 1/4 1-1/2 20-104-104 8.90 20-104-164 9.08 ticN coatED
5/32 3/16 5/16 2 20-104-106 11.42 20-104-166 11.62 • Lower friction, higher flow speed.
3/16 3/16 3/8 2 20-104-108 11.70 20-104-168 11.90 • Reduced chip compression/cutting
7/32 1/4 7/16 2 20-104-110 14.05 20-104-170 14.31 forces.
1/4 1/4 1/2 2 20-104-112 14.60 20-104-172 14.83 Extension Of Tool Performance
5/16 5/16 1/2 2 20-104-114 19.04 20-104-174 19.35 • High hardness protects against
3/8 3/8 5/8 2 20-104-116 23.45 20-104-176 23.72 abrasive wear.
1/2 1/2 5/8 2-1/2 20-104-120 40.79 20-104-180 41.29 • High chemical stability prevents built- ToLEranCES:
5/8 5/8 3/4 3 20-104-122 78.94 20-104-182 79.44 up edge micro cracks and crater wear. Cutter Diameter: -.0005" / -.0015"
3/4 3/4 1 3 20-104-124 117.37 20-104-184 118.23 • Better surface finish and tool life. Shank Diameter: -.0001" / -.0005"

2 Flute Stub Length Micrograin 10% Cobalt Solid Carbide Single End Mills
Right Hand Spiral • Center Cutting • Uncoated Or TiN Coated • 30° Helix

10% cobalt offers
high heat protection

APPLICATIONS:
• For most general purpose applications.
UnCoaTEd [164] Tin CoaTEd [164T] • Designed for reduced deflection. uNcoatED
FLUTE
Shank
SizE diaMETEr LEngTh ovEraLL ordEr PriCE ordEr PriCE FeATureS:
#
EaCh
#
LEngTh
EaCh
1/64" 1/8" .023" 1-1/2" 20-416-400 $25.34 — — • Improved tool life and overall economy.
1/32 1/8 1/16 1-1/2 20-416-401 19.71 — —
3/64 1/8 3/32 1-1/2 20-416-405 19.71 — — tiN coatED
1/16 1/8 1/8 1-1/2 20-416-409 15.42 — —
5/64 1/8 5/32 1-1/2 20-416-410 15.68 — —
3/32 1/8 3/16 1-1/2 20-416-413 15.68 — —
1/8 1/8 1/4 1-1/2 20-416-419 14.56 20-456-401 $16.40
5/32 3/16 5/16 2 20-416-423 20.94 — — ToLEranCES:
3/16 3/16 3/8 2 20-416-429 20.32 20-456-408 22.76 Cutter Diameter
1/4 1/4 1/2 2 20-416-439 24.85 20-456-415 27.79 1/64": +.000" / -.001" B2
5/16 5/16 1/2 2 — — 20-456-418 38.18 1/32" thru 1/4": +.000" / -.002"
3/8 3/8 9/16 2 — — 20-456-421 45.77 5/16" thru 3/4": +.000" / -.003"
1/2 1/2 5/8 2-1/2 20-416-459 66.96 20-456-426 74.90 Shank Diameter: +.0000" / -.0005"
2 Flute “Tuffy” Stub Length Solid Carbide Single End Mills
Center Cutting • 30° Helix
Lower cost than
regular length
[TS-201]
Shank FLUTE ovEraLL ordEr PriCE APPLICATIONS:
SizE
diaMETEr LEngTh LEngTh # EaCh • Select shortest flute length possible
1/16" 1/8" 1/8" 1-1/2" 20-200-002 $16.83 for application.
3/32 1/8 3/16 1-1/2 20-200-003 16.73 • Offers better stability and increased
1/8 1/8 1/4 1-1/2 20-200-004 16.32 feed rates.
3/16 3/16 3/8 2 20-200-006 22.75
1/4 1/4 1/2 2 20-200-008 24.53
5/16 5/16 1/2 2 20-200-010 26.72
3/8 3/8 5/8 2 20-200-012 36.36 ToLEranCES:
7/16 7/16 5/8 2-3/4 20-200-014 57.83 Cutter Diameter
1/2 1/2 5/8 3 20-200-016 55.64 1/16" thru 1/4": +.000" / -.002"
5/8 5/8 7/8 3-1/4 20-200-020 106.79 5/16" thru 3/4": +.000" / -.003"
3/4 3/4 1 3-1/2 20-200-024 163.15 Shank Diameter: -.0001" / -.0002"
