MACHINERY • Drill Presses
668

Bench Drill Press Radial Arm Drill Press

Combines performance
and economy into one

feAtures: feAtures:
• One-handed belt tensioning allows for • Durable cast iron head, table and base.
rapid speed changes. • Extended reach.
• Power switch features a safety key and • Tilting drill head that is ideal for large or
large, paddle-style off button. odd-shaped workpieces.
• Integrated depth stop makes repetitive • The head of the drill press moves 12-1/2"
drilling quick and easy. forward or backward and tilts 90° left and
• Xacta-X laser system easily identifies 45° right.
the drill center. • Table tilts 45° to the right & left and swivels 360°
• Long-lasting, built-in LED work light around the column.
reduces shadows. • The table also tilts 45° left or right allowing easy
†Ships direct from factory. machining of holes at almost any angle.
• Spindle supported by high quality ball bearings.
• Rack and pinion table raiser.
• 1/2" through table & base slots for easy
mounting & clamping of workpiece.
MoDel oRDeR PRiCe
# # eACH APPLiCAtiOns: inCLudes:
JDP-15B 87-115-112 $599.99 • Designed for general purpose • Spindle depth stop.
intermittent use. • Front mounted safety, paddle on/off switch.
SPeCifiCATionS: • Drill chuck & key.
Stock Number ......................................................................................716200
Swing .......................................................................................................... 15" SPeCifiCATionS:
Chuck Size ................................................................................................ 5/8" Amps (AC) .....................................................4.8
Spindle Travel .........................................................................................3-1/8" Spindle Speeds ................................................5
Spindle Distance To Table (Maximum) ...............................................18-5/16" Spindle Travel ........................................ 3-5/32"
Table Size ..............................................................................17"L x 12-1/2"W Spindle To Table ...........................................15"
Spindle Taper ....................................................................................MT-2/JT-3 Table Work Surface ..........................8-7/8" x 9"
Column Diameter ...................................................................................2-3/4" T-Slot ...........................................................1/2"
Number Of Spindle Speeds .........................................................................16 Overall Dimensions ............37"H x 10"W x 33"D
Range Of Spindle Speeds ....................................................210 ~ 3,500 RPM
Base Size .................................................................................... 11-3/8" x 18" Swing MoToR PoweR DRilling TAPeR SPinDle MoDel oRDeR PRiCe
Motor ................................................................................. 3/4 HP, 1 PH, 115V CAPACiTy SPeeD # # eACH
Net Weight ........................................................................................... 154 lbs. 9" to 33" 1/2 HP 115V 5/8" MT2 575 - 3,520 RPM 80341A 87-115-365 $449.99
Chip Removal Tools

With Removable Shovel APPLiCAtiOns:
Model • Accident-free removal of chips and emptying chip
#Cp450 trays from hazardous areas on your machinery.
feAtures:
• 5" guard and strong handle ensure a firm grip,
essential for hand safety.
• Special and effective shovel clamping design.
Model
#Cp550 • One tool can handle both curled chips and powder chips.
• Handle length: 6"
• Shovel width: 4.75"
• Shovel height: 2.75"
Model #CP1070
• 2 piece rod construction.
Model
#Cp660
oveRAll MoDel oRDeR PRiCe
lengTH # # eACH
18" CP450 67-803-090 $11.29
22" CP550 67-803-091 13.39
Model
#Cp1070 26" CP660 67-803-092 15.49
42" CP1070 67-803-093 24.99
Chip Hook
APPLiCAtiOns: feAtures:
Benefits: • For removing chips and cleaning • Black finished steel hooks.
the chip trays on your machines.
• Length: 24"
• Complete with a 5" special guard
to protect your hand. Model inCLudes:
#sp2550
• NogaGrip handle designed for • Plastic protective cap.
maximum comfort in your hand.
MoDel oRDeR PRiCe
DeSCRiPTion
# # eACH
24" Chip Hook SP2550 67-803-060 $24.49
Model
#sp2600 Shovel for 24" Chip Hook SP2600 67-803-061 6.99
