System overview
   C29
             AX system




           The AX system is for axial grooving with small diameters. A
           special characteristic of the design is that the insert needs no
           support in the cutting area.







              Tool shank with AX parting
              and grooving module


                                                                                           h





                                                                                   h/ h = 16 - 25 mm
                                                                                    1
                                                                                   s = 3,0 mm
                                                                                      = 10 mm
                                                                                   D min
                                                        h 1













                                                                                   h
                     s



                                                                         h/ h = 16 - 25 mm           D min
                                                                          1
                                                                         s = 3,0 mm
                                                                            = 10 mm
                                                                         D min
                     Monoblock tool
                                              h 1










      Parting and grooving / Introduction  System characteristics   Benefits

           ○ Neutral insert
                                                                ○ May be applied in left-hand and right-hand tools
                                                                ○  Optimum solution in terms of costs for every application
           ○  Monoblock and modular tools
