End Mill Holders

80 Production Toolholding Solutions

END MILL HOLDERS

C

B

BT TAPER
BT 40
Size Part Number Style B (Dia.) C Socket Depth E F H Set Screw (Incl.) Tightening Torque
B40-10EM1 2 1.75 2.38 -
1” B40-10EM4 2 2.00 4.00 4.44 - 029-926
B40-10EM6 2 6.00 4.50 -
1.12 1.00 69 ft./lbs.
B40-12EM2 2 2.00 -
1 1/4” 2.50
B40-12EM4 2 2.38 - 029-922
4.00
1 1/2” B40-15EM4 2 2.62 -
BT TAPER WITH SIMULFIT DUAL CONTACT TAPER
®
BT 30

Size Part Number Style B (Dia.) C Socket Depth E F H Set Screw (Incl.) Tightening Torque
1/4" B30F-25EM238 2 0.81 0.38 - - 029-018 7 ft./lbs.
3.31
3/8" B30F-37EM238 2 2.38 0.75 - - 029-023 12 ft./lbs.
1.38
1/2" B30F-50EM238 2 2.00 0.88 - - 029-917 17 ft./lbs.
5/8" B30F-62EM250 2 1.44 2.24 0.94 - - 029-918 31 ft./lbs.
2.50
3/4" B30F-75EM250 2 2.00 2.25 1.00 - - 029-925 45 ft./lbs.
1" B30F-10EM275 2 2.38 2.75 2.50 1.12 1.00 - 029-926 69 ft./lbs.

BT 40
Size Part Number Style B (Dia.) C Socket Depth E F H Set Screw (Incl.) Tightening Torque
1/2" B40F-50EM2 2 1.25 2.25 3.00 0.88 - - 029-917 17 ft./lbs.
5/8" B40F-62EM2 2 1.50 3.50 0.94 - - 029-918 31 ft./lbs.
3/4" B40F-75EM3 2 1.75 3.38 2.38 1.00 - - 029-925 45 ft./lbs.
1" B40F-10EM4 2 2.00 4.00 4.44 - 029-926
1.12 1.00 69 ft./lbs.
1 1/4" B40F-12EM4 2 2.50 2.38 - 029-922
Other sizes available upon request. Please call Parlec or your local Parlec representative for more information. See page 78 for specifications.
