End Mill Holders

Production Toolholding Solutions 85

END MILL HOLDERS

C C C
H

B B B

Style 1-Short Projection Style 2-Extended Projection Style 3-Long Projection

CAT TAPER
CAT 50
Size Part Number Style B (Dia.) C Socket Depth E F H Set Screw (Incl.) Tightening Torque
C50-10EM1 1 2.75 1.62" 2.50 -
C50-10EM4 2 4.00" 4.44 -
1" 1.12 1.00 029-926 69 ft./lbs.
C50-10EM6 2 2.00 6.00" 4.44 -
C50-10EM8 3 8.00" 4.44 4.50
C50-12EM2 2 2.75 2.62 3.50 -
C50-12EM4 2 2.50 4.00 3.35 -
1 1/4"
C50-12EM6 2 6.00 3.35 -
C50-12EM8 2 8.00 3.35 -
C50-15EM2 2 2.75 2.62 2.25 1.12 1.00 - 029-922 69 ft./lbs.
C50-15EM4 2 4.00 4.50 -
1 1/2"
C50-15EM6 2 6.00 4.50 -
C50-15EM8 2 8.00 4.50 -
C50-20EM5 2 3.75" 5.62 3.50 -
2" C50-20EM7 2 7.62 3.50 1.41 1.50 -
C50-20EM9 2 9.62 3.50 - 029-928 80 ft./lbs.
2 1/2" C50-25EM6 2 4.00 6.50 4.00 1.50 1.56 -
10 mm C50-M10EM2 2 1.00 2.50 4.25 0.75 - - 029-902 12 ft./lbs.
12 mm C50-M12EM2 2 1.25 2.62 4.25 - -
0.88 029-917 17 ft./lbs.
14 mm C50-M14EM2 2 1.50 2.62 4.38 - -
16 mm C50-M16EM3 2 3.75 2.13 0.94 - - 029-918 31 ft./lbs.
20 mm C50-M20EM3 2 1.75 3.75 2.25 1.00 - - 029-925 43 ft./lbs.
C50-M25EM4 2 2.00 4.00 3.00 - 029-926
25 mm
C50F-M20EM4 2 4.00 3.00 -
32 mm C50-M32EM4 2 2.50 4.00 2.60 1.12 1.00 - 029-922 69 ft./lbs.
40 mm C50-M40EM4 2 2.75 4.00 3.25 -
Other sizes available upon request. Please call Parlec or your local Parlec representative for more information. See page 78 for specifications.
