End Mill Holders

86 Production Toolholding Solutions

END MILL HOLDERS

C C C
H

B B B

Style 1-Short Projection Style 2-Extended Projection Style 3-Long Projection

CAT TAPER WITH AD/B COOLANT

CAT 40
Size Part Number Style B (Dia.) C Socket Depth E F H Set Screw (Incl.) Tightening Torque
1/8" C40BC-01EM1 2 1.75 3.00 0.38 - - 029-014 3 ft./lbs.
0.69
3/16" C40BC-18EM2 2 2.50 0.50 - - 4 ft./lbs.
029-018
1/4" C40BC-25EM2 2 0.88 2.50 0.38 - - 7 ft./lbs.
3.80
5/16" C40BC-31EM2 2 2.50 0.60 - - 9 ft./lbs.
1.00 029-023
3/8" C40BC-37EM2 2 2.50 0.75 - - 12 ft./lbs.
1/2" C40BC-50EM2 2 1.25 2.62 3.80 0.88 - - 029-917 17 ft./lbs.
5/8" C40BC-62EM2 2 1.50 2.75 3.62 0.94 - 31 ft./lbs.
C40BC-75EM1 1 1.75 2.37 - 029-918
3/4" 1.75 1.00 45 ft./lbs.
C40BC-75EM3 3 3.50 3.94 -
C40BC-10EM1 1 1.75 2.38 -
1" 2.00 029-926
C40BC-10EM4 2 4.00 4.50 -
1.12 1.00 69 ft./lbs.
1 1/4" C40BC-12EM4 2 2.50 4.00 3.75 -
029-922
1 1/2" C40BC-15EM4 2 2.62 4.00 2.38 -
Other sizes available upon request. Please call Parlec or your local Parlec representative for more information. See page 78 for specifications.
