Shanks
VTS Straight shank and taper neck

ød1 ød

S
α L3
L2
L1
S = Connection screw size

Dimensions (in) Shank
Cat. No. ød1 Stock α ød ød1 L1 L2 ød L3 S material

VTS050L300S05US S ● 85° 0.500 0.300 3.000 1.000 0.930 S05
VTS050L400S05US ● α 89° 0.500 0.300 4.000 1.500 1.300 S05
L3
L2
VTS062L500S06US ● 85° 0.625 L1 0.370 5.000 1.380 1.283 S06
VTS062L630S06US ● 89° 0.625 0.364 6.300 2.170 1.750 S06
VTS062L550S08US ● 85° 0.625 0.480 5.500 0.870 0.770 S08
VTS075L650S08US ● 89° 0.750 0.480 6.500 3.150 2.770 S08
VTS075L550S10US ● 85° 0.750 0.598 5.500 0.880 0.000 S10 Steel
VTS100L670S10US ● 85° 1.000 0.598 6.700 1.600 0.000 S10
VTS075L750S10US ● 89° 0.750 0.600 7.500 3.150 2.950 S10
VTS100L630S12US ● 85° 1.000 0.720 6.300 1.600 - S12
VTS125L750S12US ● 85° 1.250 0.720 7.500 3.150 - S12
VTS100L800S12US ● 89° 1.000 0.720 8.000 3.750 3.400 S12
VTS037L350S05UC ● 89° 0.375 0.300 3.500 1.500 0.000 S05
VTS050L450S05UC ● 89° 0.500 0.300 4.500 2.500 1.400 S05
VTS062L600S05UC ● 89° 0.625 0.300 6.000 4.000 3.900 S05
VTS050L550S06UC ● 89° 0.500 0.364 5.500 2.500 2.470 S06
VTS062L650S06UC ● 89° 0.625 0.364 6.500 3.500 3.380 S06
VTS062L650S08UC ● 89° 0.625 0.480 6.500 3.500 3.440 S08 Carbide
VTS075L700S08UC ● 89° 0.750 0.480 7.000 4.000 3.900 S08
VTS075L650S10UC ● 89° 0.750 0.600 6.500 4.000 0.000 S10
VTS075L880S10UC ● 89° 0.750 0.600 8.800 6.300 6.240 S10
VTS100L1000S12UC ● 89° 1.000 0.720 10.00 5.500 - S12
VTS075L550S06UW ● 85° 0.750 0.370 5.500 2.240 0.000 S06
VTS062L670S06UW ● 89° 0.625 0.364 6.700 2.180 1.770 S06 Tungsten 10
VTS075L670S08UW ● ød1 89° 0.750 0.480 6.700 3.150 ød 2.70 S08

Shanks α L3 L2
S
VTSD-W-A L1 Straight shank and taper neck with coolant hole Endmills

ød1 ød

S α L3
L2
L1

S = Connection screw size
Dimensions (mm)
Cat. No. Stock Shank

α ød ød1 L1 L2 L3 S material
VTSD12L110S06-W-A 89° 12 9.6 110 60 59 S06
VTSD16L170S06-W-A 89° 16 9.6 170 120 116 S06 Tungsten
d : Stocked items
: Stocked in Japan

Relating Cutting Conditions Technical reference 10–21
pages (10-23) (14-1)
