L/D = 8
+ 0.05
New øDc 0 øDs h6 øD Tolerance: øDc
0
R Rs Inch +0.002
+0.05
Metric 0
Inch
Drill dia. Dimensions (inch)
øDc Cat. No. Stock Pocket Clamping key Applicable head
(inch) øDs øD r rs L size (included)
0.394 - 0.409 TIDU0394F0625-8 0.625 0.787 3.150 1.890 5.677 10 K-TID10-19.99 DMP100 - DMP104
0.413 - 0.429 TIDU0413F0625-8 0.625 0.787 3.307 1.890 5.835 10 K-TID10-19.99 DMP105 - DMP109
0.433 - 0.449 TIDU0433F0625-8 0.625 0.787 3.465 1.890 6.008 11 K-TID10-19.99 DMP110 - DMP114
0.453 - 0.469 TIDU0453F0625-8 0.625 0.787 3.622 1.890 6.165 11 K-TID10-19.99 DMP115 - DMP119
0.472 - 0.488 TIDU0472F0625-8 0.625 0.787 3.780 1.890 6.339 12 K-TID10-19.99 DMP120 - DMP124
0.492 - 0.508 TIDU0492F0625-8 0.625 0.787 3.937 1.890 6.496 12 K-TID10-19.99 DMP125 - DMP129
0.512 - 0.528 TIDU0512F0625-8 0.625 0.787 4.094 1.890 6.677 13 K-TID10-19.99 DMP130 - DMP134
0.532 - 0.547 TIDU0532F0625-8 0.625 0.787 4.252 1.890 6.835 13 K-TID10-19.99 DMP135 - DMP139
0.551 - 0.567 TIDU0551F0625-8 0.625 0.787 4.409 1.890 7.091 14 K-TID10-19.99 DMP140 - DMP144
0.571 - 0.587 TIDU0571F0625-8 0.625 0.787 4.567 1.890 7.252 14 K-TID10-19.99 DMP145 - DMP149
0.591 - 0.626 TIDU0591F0750-8 0.750 0.984 4.724 1.969 7.626 15 K-TID10-19.99 DMP150 - DMP159
0.630 - 0.665 TIDU0630F0750-8 0.750 0.984 5.039 1.969 8.004 16 K-TID10-19.99 DMP160 - DMP169
0.669 - 0.705 TIDU0669F0750-8 0.750 0.984 5.354 1.969 8.382 17 K-TID10-19.99 DMP170 - DMP179
0.709 - 0.744 TIDU0709F1000-8 1.000 1.260 5.669 2.205 8.996 18 K-TID10-19.99 DMP180 - DMP189
0.748 - 0.783 TIDU0748F1000-8 1.000 1.260 5.984 2.205 9.370 19 K-TID10-19.99 DMP190 - DMP199
Metric
Drill dia. Dimensions (mm)
øDc Cat. No. Stock Pocket Clamping key Applicable head
(mm) øDs øD r rs L size (included)
10.0 - 10.4 TID100F16-8 16 20 80 48 144.2 10 K-TID10-19.99 DMP100 - DMP104
11 10.5 - 10.9 TID105F16-8 16 20 84 48 148.2 10 K-TID10-19.99 DMP105 - DMP109
20
TID110F16-8
K-TID10-19.99 DMP110 - DMP114
11.0 - 11.4
11
152.6
88
16
48
11.5 - 11.9 TID115F16-8 16 20 92 48 156.6 11 K-TID10-19.99 DMP115 - DMP119
K-TID10-19.99 DMP120 - DMP124
12
16
20
12.0 - 12.4
48
161.0
TID120F16-8
96
Drilling Tools 12.5 - 12.9 TID125F16-8 16 20 100 48 165.0 12 K-TID10-19.99 DMP125 - DMP129
K-TID10-19.99 DMP130 - DMP134
104
169.6
20
48
13.0 - 13.4
TID130F16-8
16
13
TID135F16-8
K-TID10-19.99 DMP135 - DMP139
48
13.5 - 13.9
173.6
20
16
108
13
14.0 - 14.4
K-TID10-19.99 DMP145 - DMP149
14
184.2
16
TID145F16-8
14.5 - 14.9 TID140F16-8 16 20 112 48 180.1 14 K-TID10-19.99 DMP140 - DMP144
116
48
20
15.0 - 15.9 TID150F20-8 20 25 120 50 193.7 15 K-TID10-19.99 DMP150 - DMP159
16.0 - 16.9 TID160F20-8 20 25 128 50 203.3 16 K-TID10-19.99 DMP160 - DMP169
17.0 - 17.9 TID170F20-8 20 25 136 50 212.9 17 K-TID10-19.99 DMP170 - DMP179
18.0 - 18.9 TID180F25-8 25 32 144 56 228.5 18 K-TID10-19.99 DMP180 - DMP189
19.0 - 19.9 TID190F25-8 25 32 152 56 238.0 19 K-TID10-19.99 DMP190 - DMP199
