DRILLS • High Speed Steel Jobbers
144

gold-P coated High Speed Steel Jobbers Length Drills
135° Split Point • Right Hand QuanTiTy Per Package
Size QuanTiTy
QuanTiTy BreakS: 3/64" thru 5/16" 10
Package Quantity: Less 10% 21/64" thru 1/2" 5
60+ Pieces: Less 15% Prices shown are per drill.

TiN tip provides DecimaL FLuTe OveraLL OrDer Price DecimaL FLuTe OveraLL OrDer Price
longer tool life Size DiameTer LengTH LengTH # eacH Size DiameTer LengTH LengTH # eacH
aPPLiCatiOns: 3/64" .04688" 3/4" 1-3/4" 01-999-000 $1.52 9/32" .28125" 2-15/16" 4-1/4" 01-999-015 $3.99
• Drilling in steel, cast steel alloyed and 1/16" .06250" 7/8" 1-7/8" 01-999-001 1.58 19/64" .29688" 3-1/16" 4-3/8" 01-999-016 4.49
non-alloyed, grey cast iron, graphite & 5/64" .07813" 1" 2" 01-999-002 1.58 5/16" .31250" 3-3/16" 4-1/2" 01-999-017 4.79
01-999-003
01-999-018
.32813"
21/64"
5.48
1-1/4"
1.58
.09375"
3-5/16"
4-5/8"
3/32"
2-1/4"
malleable iron. 7/64" .10938" 1-1/2" 2-5/8" 01-999-004 1.58 11/32" .34375" 3-7/16" 4-3/4" 01-999-019 5.98
features: 1/8" .12500" 1-5/8" 2-3/4" 01-999-005 1.58 23/64" .35938" 3-1/2" 4-7/8" 01-999-020 6.62
• Bright body with TiN coating on 9/64" .14063" 1-3/4" 2-7/8" 01-999-006 1.75 3/8" .37500" 3-5/8" 5" 01-999-021 6.72
working part. 5/32" .15625" 2" 3-1/8" 01-999-007 1.80 25/64" .39063" 3-3/4" 5-1/8" 01-999-022 7.63
• 135° split point on sizes .059" 11/64" .17188" 2-1/8" 3-1/4" 01-999-008 1.92 13/32" .40625" 3-7/8" 5-1/4" 01-999-023 8.03
diameter and over. 3/16" .18750" 2-5/16" 3-1/2" 01-999-009 2.13 27/64" .42188" 3-15/16" 5-3/8" 01-999-024 8.64
9.41
• Right hand spiral and wider flutes. 13/64" .20313" 2-7/16" 3-5/8" 01-999-010 2.57 7/16" .43750" 4-1/16" 5-1/2" 01-999-025 10.33
01-999-011
3-3/4"
7/32"
.45313"
29/64"
2.70
01-999-026
5-5/8"
4-3/16"
2-1/2"
.21875"
Number Sizes & Letter Sizes 15/64" .23438" 2-5/8" 3-7/8" 01-999-012 3.01 15/32" .46875" 4-5/16" 5-3/4" 01-999-027 10.87
Also Available In Standard 1/4" .25000" 2-3/4" 4" 01-999-013 3.17 31/64" .48438" 4-3/8" 5-7/8" 01-999-028 11.74
Package Quantities, Please Call 17/64" .26563" 2-7/8" 4-1/8" 01-999-014 3.65 1/2" .50000" 4-1/2" 6" 01-999-029 12.18
High Speed Steel Jobbers Length Twist Drills
135° Split Point • Black & Bronze Oxide
QuanTiTy Per Package
Size QuanTiTy
QuanTiTy BreakS: 1/16" thru 19/64" 12
Package Quantity: Less 10% 5/16" thru 1/2" 6
60+ Pcs: Less 15% Prices shown are per drill.
[SeRieS T1HD] [SeRieS T1HD]
Engineered to increase DecimaL FLuTe OveraLL OrDer Price DecimaL FLuTe OveraLL OrDer Price
your productivity & tool life Size DiameTer LengTH LengTH # eacH Size DiameTer LengTH LengTH # eacH
1/16" .0625" 7/8" 1-7/8" 01-331-004 $1.67 19/64" .2969" 3-1/16" 4-3/8" 01-331-019 $4.53
5/64 .0781 1 2 01-331-005 1.61 5/16 .3125 3-3/16 4-1/2 01-331-020 4.82
3/32 .0938 1-1/4 2-1/4 01-331-006 1.67 21/64 .3281 3-5/16 4-5/8 01-331-021 5.79
Benefits: 7/64 .1094 1-1/2 2-5/8 01-331-007 1.67 11/32 .3438 3-7/16 4-3/4 01-331-022 6.36
• Unique flute design for superior 1/8 .1250 1-5/8 2-3/4 01-331-008 1.67 23/64 .3594 3-1/2 4-7/8 01-331-023 6.96
material removal. 9/64 .1406 1-3/4 2-7/8 01-331-009 1.74 3/8 .3750 3-5/8 5 01-331-024 7.06
• Black and bronze oxide coating reduces 5/32 .1562 2 3-1/8 01-331-010 1.87 25/64 .3906 3-3/4 5-1/8 01-331-025 8.49
friction & allows for higher speeds. 11/64 .1719 2-1/8 3-1/4 01-331-011 2.00 13/32 .4062 3-7/8 5-1/4 01-331-026 8.90
3/16 .1875 2-5/16 3-1/2 01-331-012 2.19 27/64 .4219 3-15/16 5-3/8 01-331-027 9.42
features: 13/64 .2031 2-7/16 3-5/8 01-331-013 2.51 7/16 .4375 4-1/16 5-1/2 01-331-028 9.72
• Premium grade steel. 7/32 .2188 2-1/2 3-3/4 01-331-014 2.89 29/64 .4531 4-3/16 5-5/8 01-331-029 11.15
• Heavy duty construction. 15/64 .2344 2-5/8 3-7/8 01-331-015 3.03 15/32 .4688 4-5/16 5-3/4 01-331-030 11.75
1/4 .2500 2-3/4 4 01-331-016 3.06 31/64 .4844 4-3/8 5-7/8 01-331-031 11.99
17/64 .2656 2-7/8 4-1/8 01-331-017 3.82 1/2 .5000 4-1/2 6 01-331-032 12.13
9/32 .2812 2-15/16 4-1/4 01-331-018 4.04
ultra Bor Super Premium High Speed Steel Heavy Duty Jobbers Length Drills
135° Split Point • Type 240-UB • Premium Hi-Molybdenum Steel
Number & Letter Sizes Also
Available, Please Call QuanTiTy Per Package
Size QuanTiTy
QuanTiTy BreakS: 1/16" thru 9/32" 12
Package Quantity: Less 10% 19/64" thru 1/2" 6
60+ Pcs: Less 15% Prices shown are per drill.
Designed for series 300 DecimaL FLuTe OveraLL OrDer Price DecimaL FLuTe OveraLL OrDer Price
stainless steel, except for 303 Size DiameTer LengTH LengTH # eacH Size DiameTer LengTH LengTH # eacH
1/16" .0625" 7/8" 1-7/8" 01-910-009 $1.28 19/64" .2969" 3-1/16" 4-3/8" 01-910-039 $4.11
Benefits: 5/64" .0781" 1" 2" 01-910-011 1.29 5/16" .3125" 3-3/16" 4-1/2" 01-910-041 4.38
• Much tougher than cobalt steel. 3/32" .0938" 1-1/4" 2-1/4" 01-910-013 1.29 21/64" .3281" 3-5/16" 4-5/8" 01-910-043 4.70
• Thin web design penetrates work 7/64" .1094" 1-1/2" 2-5/8" 01-910-015 1.37 11/32" .3438" 3-7/16" 4-3/4" 01-910-045 5.39
hardening stainless steel fast enough to 1/8" .1250" 1-5/8" 2-3/4" 01-910-017 1.60 23/64" .3594" 3-1/2" 4-7/8" 01-910-047 5.87
continually cut beneath the 9/64" .1406" 1-3/4" 2-7/8" 01-910-019 1.61 3/8" .3750" 3-5/8" 5" 01-910-049 6.23
chip which is hardening from deformation. 5/32" .1562" 2" 3-1/8" 01-910-021 1.69 25/64" .3906" 3-3/4" 5-1/8" 01-910-051 6.95
• 135° split point design stops drill walking, 11/64" .1719" 2-1/8" 3-1/4" 01-910-023 1.72 13/32" .4062" 3-7/8" 5-1/4" 01-910-053 7.17
holds tighter hole size and takes a smaller 3/16" .1875" 2-5/16" 3-1/2" 01-910-025 2.09 27/64" .4219" 3-15/16" 5-3/8" 01-910-055 7.55
chip resulting in less heat. 13/64" .2031" 2-7/16" 3-5/8" 01-910-027 2.32 7/16" .4375" 4-1/16" 5-1/2" 01-910-057 8.37
01-910-029
9.72
2-1/2"
.2188"
7/32"
01-910-200
3-3/4"
5-5/8"
2.46
29/64"
.4531"
4-3/16"
aPPLiCatiOns: 15/64" .2344" 2-5/8" 3-7/8" 01-910-031 2.63 15/32" .4688" 4-5/16" 5-3/4" 01-910-201 9.88
• Outperforms cobalt drills in work 1/4" .2500" 2-3/4" 4" 01-910-033 2.78 31/64" .4844" 4-3/8" 5-7/8" 01-910-059 10.39
hardening stainless steel applications. 17/64" .2656" 2-7/8" 4-1/8" 01-910-035 3.35 1/2" .5000" 4-1/2" 6" 01-910-061 10.58
9/32" .2812" 2-15/16" 4-1/4" 01-910-037 3.62
