Features:
- AlTiN+ coating extends tool life
- Polished flute face for maximum performance
- Precision ground flat for guaranteed tool orientation
- Made with premium submicron grade carbide
Product Specifications
Manufacturer Part Number | FG187-045 |
Minimum Hole Diameter (Decimal Inch) | 0.195" |
Groove Width (Decimal Inch) | 0.045" |
Groove Depth (Decimal Inch) | 0.090" |
Neck Relief (Decimal Inch) | 0.500" |
Shank Diameter (Decimal Inch) | 0.187" |
Overall Length (Decimal Inch) | 2.000" |
Material | Solid Carbide |
Coating | Uncoated |
Product Type | Grooving Tool |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Scientific Cutting Tools
Material:
Solid Carbide
Shank Diameter (Inch):
3/16"
Shank Diameter (Decimal Inch):
0.1870"
Shank Diameter (mm):
4.75mm
Groove Width (Inch):
3/64"
Groove Width (Decimal Inch):
0.0450"
Groove Width (mm):
1.14mm
Minimum Hole Diameter (Inch):
3/16"
Minimum Hole Diameter (Decimal Inch):
0.1950"
Minimum Hole Diameter (mm):
4.95mm
Overall Length (Inch):
2"
Overall Length (Decimal Inch):
2.0000"
Overall Length (mm):
50.80mm
Finish/Coating:
Uncoated
