Features:
- AlTiN+ coating for higher Surface Feet per Minute
- Shank diameter is precision ground
- Polished flute face for optimum performance
- Made with premium submicron grade carbide
Product Specifications
| Manufacturer Part Number | GT093-24A |
| Minimum Bore Diameter (Decimal Inch) | 0.500" |
| Maximum Bore Depth (Decimal Inch) | 1.500" |
| Off Set (Decimal Inch) | 0.160" |
| Groove Width (Decimal Inch) | 0.094" |
| Shank Diameter (Decimal Inch) | 0.500" |
| Overall Length (Decimal Inch) | 3.000" |
| Material | Solid Carbide |
| Coating | AlTiN |
| Product Type | Grooving Tool |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Scientific Cutting Tools
Material:
Solid Carbide
Shank Diameter (Inch):
1/2"
Shank Diameter (Decimal Inch):
0.5000"
Shank Diameter (mm):
12.70mm
Groove Width (Inch):
3/32"
Groove Width (Decimal Inch):
0.0940"
Groove Width (mm):
2.39mm
Overall Length (Inch):
3"
Overall Length (Decimal Inch):
3.0000"
Overall Length (mm):
76.20mm
Finish/Coating:
AlTiN
interval quantity:
1
