Product Specifications
| Manufacturer Part Number | LHGT055-12A |
| Off Set (Decimal Inch) | 0.110" |
| Minium Hole Diameter (Decimal Inch) | 0.375" |
| Maximum Hole Depth (Inch) | 3/4" |
| Shank Diameter (Decimal Inch) | 0.375" |
| Overall Length (Decimal Inch) | 2.500" |
| Material | Solid Carbide |
| Coating | AlTiN |
| Product Type | Grooving Tool |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Scientific Cutting Tools
Material:
Solid Carbide
Shank Diameter (Inch):
3/8"
Shank Diameter (Decimal Inch):
0.3750"
Shank Diameter (mm):
9.53mm
Minimum Hole Diameter (Inch):
3/8"
Minimum Hole Diameter (Decimal Inch):
0.3750"
Minimum Hole Diameter (mm):
9.53mm
Overall Length (Inch):
2-1/2"
Overall Length (Decimal Inch):
2.5000"
Overall Length (mm):
63.50mm
Finish/Coating:
AlTiN
interval quantity:
1
