Product Specifications
| EDP Number | U104498 |
| Product Code-ANSI | GNDFR124K-070-040 |
| Series | GND |
| Insert Width (Inch) | 0.1575" |
| Insert Width (mm) | 4.00mm |
| Head Length (Inch) | 1.6380" |
| Maximum Depth of Cut (Inch) | 0.7000" |
| Maximum Depth of Cut (mm) | 17.78mm |
| Maximum Workpiece Diameter (Inch) | 2.1654" |
| Maximum Workpiece Diameter (mm) | 55.00mm |
| Shank Width (Inch) | 0.7500" |
| Shank Height (Inch) | 0.7500" |
| Overall Length (Inch) | 5.0000" |
| Insert Holding Method | Clamp |
| Hand | Right Hand |
| Tool Holder Style | Face Grooving Tool |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Sumitomo
Hand of Holder:
Right Hand
Maximum Depth of Cut (Inch):
11/16"
Maximum Depth of Cut (Decimal Inch):
0.7000"
Maximum Depth of Cut (mm):
17.78mm
Maximum Workpiece Diameter (Inch):
2-5/32"
Maximum Workpiece Diameter (Decimal Inch):
2.1654"
Maximum Workpiece Diameter (mm):
55.00mm
Series:
GND
Toolholder Style:
Face Grooving Tool
Overall Length (Inch):
5"
Overall Length (Decimal Inch):
5.0000"
Overall Length (mm):
127.00mm
Shank Width/Diameter (Inch):
3/4"
Shank Width/Diameter (Decimal Inch):
0.7500"
Shank Width/Diameter (mm):
19.05mm
Shank Height (Inch):
3/4"
interval quantity:
1
Ships:
From California in 1-2 Days
