Product Specifications
| Manufacturer Part Number | T7336708 |
| Diameter (Decimal Inch) | 0.7500" |
| Diameter (mm) | 19.05mm |
| OAL (Decimal Inch) | 4.2500" |
| OAL (mm) | 107.95mm |
| Thread Length (Decimal Inch) | 2.0000" |
| Thread Length (mm) | 50.80mm |
| Square Length (Decimal Inch) | 0.6900" |
| Square Length (mm) | 17.53mm |
| Shank Diameter (Decimal Inch) | 0.5900" |
| Shank Diameter (mm) | 15.00mm |
| Square Size (Decimal Inch) | 0.4420" |
| Square Size (mm) | 11.23mm |
| Drill Size (Decimal Inch) | 0.6591" |
| Drill Size (mm) | 16.74mm |
| Useable Length (Decimal Inch) | 2.0000" |
| Useable Length (mm) | 50.80mm |
| Length/Diameter | 2xD |
| Number of Flutes | 4 |
| Thread Diameter (Inch) | 3/4" |
| Thread Pitch | 10 TPI |
| Series | T7336 |
| Thread Series | UNC |
| Pitch Limit | H3 |
| Chamfer Length | 1.5P-2P |
| Shank Type | Square |
| Chamfer Type | Bottoming |
| Helix Angle | 0 Degree |
| Finish | Bright |
| Material | HSS |
| Blank Standard | 302 |
| Tap Type | Hand |
