Product Specifications
| Length Of Cut (Decimal Inch) | 0.2030" |
| Length Of Cut (Inch) | 13/64" |
| Overall Length (Decimal Inch) | 2.0000" |
| Overall Length (Inch) | 2" |
| Tip (Decimal Inch) | 0.0400" |
| Angle Per Side | 20 Degree |
| Included Angle | 40 Degree |
| Number of Flutes | 4 |
| Type | II |
| Shank Diameter (Decimal Inch) | 0.1875" |
| Shank Diameter (Inch) | 3/16" |
| Metric | No |
| Coating | Uncoated |
| Center Cutting (Yes/No) | No |
| Chip Breaker (Yes/No) | No |
| Single or Double Angle | Single |
| Weldon (Yes/No) | No |
| Coolant Through (Yes/No) | No |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Angle Per Side:
20 Degree
Length Of Cut (Decimal Inch):
0.2030"
Finish/Coating:
Uncoated
Material:
Solid Carbide
Ships:
From Partner Facility
