Seco Tools 74053362 | TPGN160308 TP1606 Insert Size x 9.52mm Inscribed Circle Diameter x 0.80mm Corner Radius 3 Cutting Edge Uncoated Turning Insert

$13.17
Brand:
Seco Tools
Inscribed Circle (Inch):
3/8"
Inscribed Circle (Decimal Inch):
0.3750"
Inscribed Circle (mm):
9.52mm
Thickness (Inch):
1/8"
Thickness (Decimal Inch):
0.1250"
Thickness (mm):
3.18mm
Corner Radius (Inch):
1/32"
Corner Radius (Decimal Inch):
0.0320"
Corner Radius (mm):
0.80mm
interval quantity:
1
SKU:
23289713
Weight:
0.01 LBS
Shipping:
Calculated at Checkout
Seco Tools 74053362 | TPGN160308 TP1606 Insert Size x 9.52mm Inscribed Circle Diameter x 0.80mm Corner Radius 3 Cutting Edge Uncoated Turning Insert

Product Specifications
Manufacturer Part Number74053362
Inscribed Circle Diameter (Decimal Inch)0.375"
Inscribed Circle Diameter (mm)9.52mm
Corner Radius (Decimal Inch)0.032"
Corner Radius (mm)0.80mm
Cutting Edge Effective Length (Decimal Inch)0.618"
Cutting Edge Effective Length (mm)15.70mm
Theoretical Cutting Edge Length (Decimal Inch)0.650"
Theoretical Cutting Edge Length (mm)16.50mm
Insert Thickness (Decimal Inch)0.125"
Insert Thickness (mm)3.18mm
Clearance Angle Major (Degree)11 Degree
Cutting Edge Count3
Insert Size And ShapeTP1606
Insert Included Angle (Degree)60 Degree
MaterialCarbide
Insert HandNeutral
Insert Shape CodeT
Product TypeTurning Insert
