Product Specifications
| Manufacturer Part Number | 74054886 |
| Cutting Diameter (Decimal Inch) | 0.750" |
| Cutting Diameter (mm) | 19.05mm |
| Minimum Helical Interpolation Hole Diameter (Decimal Inch) | 0.807" |
| Minimum Helical Interpolation Hole Diameter (mm) | 20.50mm |
| Maximum Helical Interpolation Hole Diameter (Decimal Inch) | 1.409" |
| Maximum Helical Interpolation Hole Diameter (mm) | 35.80mm |
| Cutting Edge Effective Length (Decimal Inch) | 0.686" |
| Cutting Edge Effective Length (mm) | 17.43mm |
| Functional Length (Decimal Inch) | 0.871" |
| Functional Length (mm) | 22.12mm |
| Maximum Depth of Cut (Decimal Inch) | 0.685" |
| Maximum Depth of Cut (mm) | 17.40mm |
| Corner Radius (Decimal Inch) | 0.375" |
| Corner Radius (mm) | 9.53mm |
| Cutting Edge Count | 1 |
| Tool Cutting Edge Angle (Degree) | 90 Degree |
| Tool Cutting Edge Angle In Feed Direction Side (Degree) | 90 Degree |
| Maximum Ramping Angle (Degree) | 15 Degree |
| Sphere Angle (Degree) | 180 Degree |
| Material | Carbide |
| Coating | AlTiN |
| Product Type | Profile Milling Tip Insert |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Seco Tools
Material:
Carbide
Cutting Diameter (Inch):
3/4"
Cutting Diameter (Decimal Inch):
0.7500"
Cutting Diameter (mm):
19.05mm
Maximum Depth of Cut (Inch):
50/73"
Maximum Depth of Cut (Decimal Inch):
0.6850"
Maximum Depth of Cut (mm):
17.40mm
interval quantity:
1
