Product Specifications
| Manufacturer Part Number | 75009698 |
| Cutting Diameter (mm) | 100.00mm |
| Connection Bore Diameter (mm) | 40.00mm |
| Contact Surface Diameter Machine Side (mm) | 85.00mm |
| Functional Length (mm) | 45.00mm |
| Maximum Depth of Cut (mm) | 20.00mm |
| Depth of Key Way (mm) | 9.00mm |
| Keyway Width (mm) | 16.40mm |
| Cutting Pitch Density | Coarse |
| Tool Cutting Edge Angle (Degree) | 90 Degree |
| Tool Cutting Edge Angle In Feed Direction End (Degree) | 90 Degree |
| Tool Cutting Edge Angle In Feed Direction Side (Degree) | 90 Degree |
| Maximum Rotational Speed (rpm) | 5300 rpm |
| Shank Type | Arbor |
| Product Type | Indexable Square-Shoulder Face Mill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Seco Tools
Cutting Diameter (Inch):
3-15/16"
Cutting Diameter (Decimal Inch):
3.9370"
Cutting Diameter (mm):
100.00mm
Maximum Depth of Cut (Inch):
37/47"
Maximum Depth of Cut (Decimal Inch):
0.7874"
Maximum Depth of Cut (mm):
20.00mm
interval quantity:
1
