Product Specifications
| EDP Number | 23257 |
| Diameter (Decimal Inch) | 0.0625" |
| Diameter (Inch) | 1/16" |
| Diameter (mm) | 1.59mm |
| Shank Diameter (Decimal Inch) | 0.2500" |
| Shank Diameter (Inch) | 1/4" |
| Shank Diameter (mm) | 6.35mm |
| Length of Cut (Decimal Inch) | 0.1563" |
| Length of Cut (Inch) | 5/32" |
| Length of Cut (mm) | 3.97mm |
| Overall Length (Decimal Inch) | 1.0938" |
| Overall Length (Inch) | 1-3/32" |
| Overall Length (mm) | 27.78mm |
| Series | E2161 |
| Shank Style | Flat |
| Helix Angle | 30 Degree |
| Number of Flutes | 3 |
| Coating | Bright |
| Cut Type | Center Cutting |
| Cutting Direction | Right |
| Type | Square End Mill |
| Application | P |
| Material | HSSCo8 |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Mill Diameter (Inch):
1/16"
Mill Diameter (Decimal Inch):
0.0625"
Mill Diameter (mm):
1.59mm
Number of Flutes:
3
Length of Cut (Inch):
5/32"
Length of Cut (Decimal Inch):
0.1563"
Length of Cut (mm):
3.97mm
Shank Type:
Flat
Material:
HSSCo8
Finish/Coating:
Bright
Shank Diameter (Inch):
1/4"
Shank Diameter (Decimal Inch):
0.2500"
Shank Diameter (mm):
6.35mm
Application:
Center Cutting
Overall Length (Inch):
1-3/32"
Overall Length (Decimal Inch):
1.0938"
Overall Length (mm):
27.78mm
Helix Angle:
30 Degree
