Product Specifications
| EDP Number | G92940 |
| Diameter (Decimal Inch) | 0.6250" |
| Diameter (Inch) | 5/8" |
| Diameter (mm) | 15.88mm |
| Shank Diameter (Decimal Inch) | 0.6250" |
| Shank Diameter (Inch) | 5/8" |
| Shank Diameter (mm) | 15.88mm |
| Length of Cut (Decimal Inch) | 1.2500" |
| Length of Cut (Inch) | 1 1/4" |
| Length of Cut (mm) | 31.75mm |
| Overall Length (Decimal Inch) | 3.5000" |
| Overall Length (Inch) | 3-1/2" |
| Overall Length (mm) | 88.90mm |
| Corner Radius (Decimal Inch) | 0.0400" |
| Corner Radius (mm) | 1.02mm |
| Number of Flutes | 5 |
| Series | G929 |
| Shank Style | Flat |
| Helix Angle | Multi Helix |
| Coating | Y Coated |
| Material | Carbide |
| Cut Type | Center |
| Corner Type | Corner Radius |
| Type | Roughing Corner Radius End Mill |
| Application | P,K |
| Cutting Direction | Right Hand |
| Product Type | Roughing End Mill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Center Cutting (yes/no):
Yes
interval quantity:
1
