The solid carbide, 2 flute, corner radius upcut end mill for plastics has the ability to plunge and ramp due to its center cutting design, and has a slower helix which reduces lifting forces, making this an excellent choice for milling fiber-reinforced materials on vacuum table set ups.
- Slower helix reduces lifting forces, making design preferable for fiber-reinforced applications and vacuum table setups
- High rake, high relief design with large flute valley maximizes chip removal and performance
- Center cutting design improves plunging and ramping
- CNC ground in the USA
- Solid Carbide
Product Specifications
| Tool Number | 739132 |
| Cutter Diameter (Inch) | 0.5000" (1/2) |
| Length of Cut (Inch) | 1.5000" (1-1/2) |
| Overall Length (Inch) | 4.0000" (4) |
| Corner Radius (Inch) | 0.0600" |
| Flutes | 2 |
| LOC Multiple | 3x |
| Shank Diameter (Inch) | 0.5000" (1/2) |
| Coating | Uncoated |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Cutter Diameter (Inch):
1/2"
Cutter Diameter (Decimal Inch):
0.5000"
Length of Cut (Inch):
1-1/2"
Length of Cut (Decimal Inch):
1.5000"
Overall Length (Inch):
4"
Overall Length (Decimal Inch):
4.0000"
Corner Radius (Decimal Inch):
0.0600"
Number of Flutes:
2
Shank Diameter (Inch):
1/2"
Shank Diameter (Decimal Inch):
0.5000"
Shank Diameter (mm):
12.70mm
Finish/Coating:
Uncoated
