Kyocera Precision Tools TCR89191 | RCMA106T08015625AA A65 3/4" Circle Diameter x 0.394" Thickness Uncoated Ceramic Indexable Turning Insert

$55.71
Brand:
Kyocera Precision Tools
Insert Style:
RCMA
Insert Size:
106/625AA
Material:
Ceramic;Inscribed Circle (Inch)=3/4"""
Inscribed Circle (Decimal Inch):
0.7500"
Inscribed Circle (mm):
19.05mm
Thickness (Decimal Inch):
0.3940"
Thickness (mm):
10.00mm
Manufacturer's Grade:
A65
SKU:
23225898
Weight:
0.28 LBS
Minimum Purchase:
10 units
Shipping:
Calculated at Checkout

Features:

  • Insert for roll machining
  • Aluminum oxide and titanium carbide ceramic (Al2O3+TiC)
  • Application: Semi-roughing to finishing of steel, cast iron, and hard materials

Product Specifications
EDP NumberTCR89191
Inscribed Circle (Inch)3/4"
Inscribed Circle (mm)19.05mm
Thickness (Inch)0.394"
Thickness (mm)10.00mm
ApplicationRoll Machining
Coating ProcessUncoated
Cutting RangeFinishing Medium
HandNeutral
Insert GradeA65
Insert Holding MethodScrew or Clamp
Insert ShapeRound
Insert Size106/625AA
MaterialCeramic
Primary Workpiece MaterialGray Cast Iron (K) | Hardened Materials (H)
Usage ClassificationContinuous

Warning:

This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.

For more information, visit www.P65Warnings.ca.gov

Brand:
Kyocera Precision Tools
Insert Style:
RCMA
Insert Size:
106/625AA
Material:
Ceramic;Inscribed Circle (Inch)=3/4"""
Inscribed Circle (Decimal Inch):
0.7500"
Inscribed Circle (mm):
19.05mm
Thickness (Decimal Inch):
0.3940"
Thickness (mm):
10.00mm
Manufacturer's Grade:
A65
