Kyocera Precision Tools TCS89060 | RCMA106T08015625AA A66N 3/4" Circle Diameter x 0.394" Thickness PVD Coated Ceramic Indexable Turning Insert

$112.00 $78.40
(You save $33.60)
Brand:
Kyocera Precision Tools
Insert Style:
RCMA
Insert Size:
106/625AA
Material:
Ceramic;Inscribed Circle (Inch)=3/4"""
Inscribed Circle (Decimal Inch):
0.7500"
Inscribed Circle (mm):
19.05mm
Thickness (Decimal Inch):
0.3940"
Thickness (mm):
10.00mm
interval quantity:
10
SKU:
23226009
UPC:
Weight:
0.28 LBS
Minimum Purchase:
10 units
Shipping:
Free Shipping

Features:

  • Insert for roll machining
  • TiN PVD coated aluminum oxide and titanium carbide ceramic (TiN coated Al2O3+TiC) insert grade
  • Application: Semi-roughing to finishing of hard materials

Product Specifications
EDP NumberTCS89060
Inscribed Circle (Inch)3/4"
Inscribed Circle (mm)19.05mm
Thickness (Inch)0.394"
Thickness (mm)10.00mm
ApplicationRoll Machining
Coating ProcessPVD
Cutting RangeFinishing Medium
HandNeutral
Insert GradeA66N
Insert Holding MethodScrew or Clamp
Insert ShapeRound
Insert Size106/625AA
MaterialCeramic
Primary Workpiece MaterialHardened Materials (H)
Usage ClassificationContinuous
