Product Specifications
| # Manufacturer Number | 0726663 |
| Diameter (mm) | 10.50mm |
| Shank Size (mm) | 11.00mm |
| Flute Length (mm) | 137.00mm |
| Overall Length (mm) | 197.00mm |
| Drill Point Angle | 140 Degree |
| Number of Flute | 2 |
| Material | Carbide |
| Finish / Coating | Aqua EX |
| Coolant Through | Yes |
| Cutting Direction | Right |
| Flute Type | Conventional Spiral |
| Shank Type | Endmill Type Shank |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Nachi
Drill Bit Size (Inch):
0.4134
Drill Bit Size (Decimal Inch):
0.4134
Drill Bit Size (mm):
10.5
Material:
Carbide
Finish/Coating:
Aqua EX
Overall Length (Inch):
7-3/4 "
Overall Length (Decimal Inch):
7.7559";Overall Length (mm)=197.00mm"
Flute Length (Inch):
5-2/5";Flute Length (Decimal Inch)=5.3937""
Flute Length (mm):
137.00mm
Drill Point Angle:
140 Degree
Coolant Through:
Yes
Shank Type:
Endmill Type Shank
