Pramet 160B06R-S90CN10N18 | 6.299" Diameter x 1.969" Functional Length Indexable Slotting Cutter

$1,950.40
Ships:
From Partner Facility
Ships:
From Partner Facility
interval quantity:
1
SKU:
23144773
Weight:
89.95 LBS
Minimum Purchase:
1 unit
Shipping:
Free Shipping
Disc mill with positve/negative geometry which utilises 12 off CNHQ 1005.. double-sided inserts, cutting diameter 160 mm with 90° approach angle and 40 mm connection bore according to DIN 8030-B, 50 mm protrusion length for deep slot milling with a width of cut of 14,0 ÷ 18,5 mm.

Product Specifications
EDP Number6760162
Face Effective Cutting Edge Count6
Peripheral Effective Cutting Edge Count12
Insert Index Count12
Max Cutting Depth (mm)44 mm
Axial Rake Angle5
Radial Rake Angle-8
Max Rotational Speed6900
Connection Bore Diameter (mm)40 mm
Hub Diameter (mm)70 mm
Cutting Diameter (mm)160 mm
Cutting Diameter (Inch)6.299"
Overall Length (mm)90 mm
Overall Length (Inch)3.543"
Number of Peripheral Edges in The Tool12
