Features:
- Carbide Tipped Full Center
Product Specifications
| # MFG | 74173 |
| Taper | 17 Brown & Sharpe |
| Accuracy | ± 0.00005 |
| Overall Length (Inch) | 14.500" |
| Point Diameter (Inch) | 3.156" |
| Center Style | Full Carbide Center |
| Taper Length (Inch) | 9.750" |
| D (Inch) | 2.750" |
| Carbide Tip Diameter (Inch) | 1.500" |
| Series | Standard Length Dead Centers |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Riten
Length (Inch):
1"
Length (Decimal Inch):
9.7500"
Length (mm):
247.65mm
Overall Length (Inch):
1"
Overall Length (Decimal Inch):
14.5000"
Overall Length (mm):
368.30mm
Diameter (Inch):
3-5/32"
Diameter (Decimal Inch):
3.1560"
Diameter (mm):
80.16mm
