Features:
- High-performance point design stabilizes on entry for exceptional hole size and cylindricity while also allowing for low thrust force and extended tool life
- Internal coolant hole improves coolant flow to extend tool life and aid in chip evacuation
- 4-margin design improves hole straightness and roundness while providing improved stability for difficult applications like cross holes and when exiting on angle
- Proprietary Ti-NAMITE-X coating and industry leading carbide substrate provides exceptional wear resistance and toughness for demanding applications
- Recommended for materials ≤ 50HRc (475 Bhn)
Product Specifications
| Manufacturer Part Number | 56510 |
| Size | 9/64" |
| Cutting Diameter (Inch) | 9/64" |
| Cutting Diameter (Decimal Inch) | 0.141" |
| Cutting Diameter (mm) | 3.57mm |
| Shank Diameter (Decimal Inch) | 0.236" |
| Shank Diameter (mm) | 6.00mm |
| Flute Length (Decimal Inch) | 1.921" |
| Flute Length (mm) | 48.80mm |
| Usable Length (Decimal Inch) | 1.710" |
| Usable Length (mm) | 43.44mm |
| Overall Length (Decimal Inch) | 3.417" |
| Overall Length (mm) | 86.80mm |
| Shank Length (Decimal Inch) | 1.417" |
| Shank Length (mm) | 36.00mm |
| Point Length (Decimal Inch) | 0.028" |
| Point Length (mm) | 0.70mm |
| Shank Diameter Tolerance | h6 |
| Point Angle (Degree) | 137 Degree |
| Flute Type | Spiral |
| Number of Margins | 4 |
| Number of Flutes | 2 |
| Reach (xD) | 12xD |
| Center Cutting | No |
| Double Margins | Yes |
| High Performance | Yes |
| Self Centering | Yes |
| Coating | TX (Ti-NAMITE-X) |
| Product Type | Extra Long Drill Bit |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
SGS
Cutting Diameter (Inch):
9/64"
Cutting Diameter (Decimal Inch):
0.1410"
Cutting Diameter (mm):
3.57mm
Shank Diameter (Inch):
21/89"
Shank Diameter (Decimal Inch):
0.2360"
Shank Diameter (mm):
6.00mm
Overall Length (Inch):
3-5/12"
Overall Length (Decimal Inch):
3.4170"
Overall Length (mm):
86.80mm
Size:
9/64"
Finish/Coating:
TX (Ti-NAMITE-X)
Number of Flute:
2
Point Angle (Degree):
137 Degree
