Product Specifications
| Manufacturer Part Number | DH453173 |
| Cutting Diameter (Inch) | 47/69" |
| Cutting Diameter (Decimal Inch) | 0.681" |
| Cutting Diameter (mm) | 17.30mm |
| Shank Diameter (Inch) | 17/24" |
| Shank Diameter (Decimal Inch) | 0.708" |
| Shank Diameter (mm) | 18.00mm |
| Flute Length (Inch) | 6-52/71" |
| Flute Length (Decimal Inch) | 6.732" |
| Flute Length (mm) | 171.00mm |
| Overall Length (Inch) | 8-57/77" |
| Overall Length (Decimal Inch) | 2.740" |
| Overall Length (mm) | 222.00mm |
| Point Length (Decimal Inch) | 0.124" |
| Point Length (mm) | 3.15mm |
| Number of Flutes | 2 |
| Shank Tolerance | h6 |
| Hole Tolerance | m7 |
| Material | Carbide |
| Coating | TiAIN |
| Product Type | Dream Drill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Diameter
(Inch):
47/69";Diameter
(Decimal Inch)=0.6810"""""
Diameter
(mm):
17.30mm
Shank Diameter
(Inch):
17/24";Shank Diameter
(Decimal Inch)=0.7080"""""
Shank Diameter
(mm):
18.00mm
Flute Length
(Inch)):
6-52/71";Flute Length
(Decimal Inch))=6.7320"""""
Flute Length
(mm):
171.00mm
Point Length
(Inch):
1/8";Point Length (Decimal Inch)=0.1240"""""
Point Length
(mm):
3.15mm
Helix
Angle:
30 Degree
Coating:
TiAIN
Material:
Carbide
Cutting
Direction:
Right Hand
Number of Flutes:
2
interval quantity:
1
