Product Specifications
| Manufacturer Part Number | E5H94923 |
| Mill Diameter (Inch) | 1" |
| Mill Diameter (Decimal Inch) | 1.000" |
| Mill Diameter (mm) | 25.40mm |
| Shank Diameter (Inch) | 1" |
| Shank Diameter (Decimal Inch) | 1.000" |
| Shank Diameter (mm) | 25.40mm |
| Length of Cut (Inch) | 7" |
| Length of Cut (Decimal Inch) | 7.000" |
| Length of Cut (mm) | 177.80mm |
| Overall Length (Inch) | 10" |
| Overall Length (Decimal Inch) | 10.000" |
| Overall Length (mm) | 254.00mm |
| Number of Flutes | 4 |
| Helix Angle (Degree) | 30 Degree |
| Coating | Bright Coated |
| Material | Carbide |
| Product Type | Square End Mill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Cutting Diameter (Inch):
1"
Cutting Diameter (Decimal Inch):
1.0000"
Cutting Diameter (mm):
25.40mm
Shank Diameter (Inch):
1"
Shank Diameter (Decimal Inch):
1.0000"
Shank Diameter (mm):
25.40mm
Length of Cut (Inch):
7"
Length of Cut (Decimal Inch):
7.0000"
Length of Cut (mm):
177.80mm
Overall Length (Inch):
10"
Overall Length (Decimal Inch):
10.0000"
Overall Length (mm):
254.00mm
Number of Flutes:
4
Helix Angle:
30 Degree
Finish/Coating:
Bright Coated
Material:
Carbide
interval quantity:
1
