Product Specifications
| Cutter Diameter (Decimal Inch) | 0.7500" |
| Cutter Diameter (Inch) | 3/4" |
| Neck Diameter (Decimal Inch) | 0.6840" |
| Length Of Cut (Decimal Inch) | 1.2500" |
| Length Of Cut (Inch) | 1-1/4" |
| Overall Reach (Decimal Inch) | 2.0000" |
| Overall Reach (Inch) | 2" |
| Overall Length (Decimal Inch) | 4.0000" |
| Overall Length (Inch) | 4" |
| Number of Flutes | 4 |
| Shank Diameter (Decimal Inch) | 0.7500" |
| Shank Diameter (Inch) | 3/4" |
| Metric (Yes/No) | No |
| Finish/Coating | PCD |
| Center Cutting (Yes/No) | Yes |
| Double or Single End | Single |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Mill Diameter (Inch):
3/4"
Mill Diameter (Decimal Inch):
0.7500"
Number of Flutes:
4
Material:
Carbide
Finish/Coating:
PCD
Length of Cut (Inch):
1-1/4"
Length of Cut (Decimal Inch):
1.2500"
Shank Type:
Reduced
Overall Reach (Inch):
2"
Overall Reach (Decimal Inch):
2.0000"
Overall Length (Inch):
4"
Overall Length (Decimal Inch):
4.0000"
Shank Diameter (Inch):
3/4"
Shank Diameter (Decimal Inch):
0.7500"
Single or Double End:
Single
Application:
Diamond Tooling
Center Cutting:
Yes
Ships:
From Partner Facility
