Product Specifications
| EDP Number | U104396 |
| Product Code-ANSI | GNDFR164M-090-180 |
| Series | GND |
| Insert Width (Inch) | 0.1575" |
| Insert Width (mm) | 4.00mm |
| Head Length (Inch) | 1.8350" |
| Maximum Depth of Cut (Inch) | 0.9000" |
| Maximum Depth of Cut (mm) | 22.86mm |
| Maximum Workpiece Diameter (Inch) | 11.8110" |
| Maximum Workpiece Diameter (mm) | 300.00mm |
| Shank Width (Inch) | 1.0000" |
| Shank Height (Inch) | 1.0000" |
| Overall Length (Inch) | 6.0000" |
| Insert Holding Method | Clamp |
| Hand | Right Hand |
| Tool Holder Style | Face Grooving Tool |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Sumitomo
Hand of Holder:
Right Hand
Maximum Depth of Cut (Inch):
29/32"
Maximum Depth of Cut (Decimal Inch):
0.9000"
Maximum Depth of Cut (mm):
22.86mm
Maximum Workpiece Diameter (Inch):
11-13/16"
Maximum Workpiece Diameter (Decimal Inch):
11.8110"
Maximum Workpiece Diameter (mm):
300.00mm
Series:
GND
Toolholder Style:
Face Grooving Tool
Overall Length (Inch):
6"
Overall Length (Decimal Inch):
6.0000"
Overall Length (mm):
152.40mm
Shank Width/Diameter (Inch):
1"
Shank Width/Diameter (Decimal Inch):
1.0000"
Shank Width/Diameter (mm):
25.40mm
Shank Height (Inch):
1"
interval quantity:
1
Ships:
From California in 1-2 Days
